System And Components
300-4181 TANK GP-FUEL -FAST FILLS/N MSY1-UP
Group No: 300-4181
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G0244 | 1 GAUGE GP-FUEL LEVEL (TANK) | 1 | |
| 7V6480 | SCREW-PAN HEAD (6-32X6.35-MM) | 2 | |
| 3E7753 | 2 FLOAT AS | 1 | |
| 6G7803 | 3 VENT AS | 1 | |
| 8M3368 | 4 VALVE-CHECK | 1 | |
| 9D0630 | 5 CAP-DUST | 1 | |
| 1159186 | 6 TANK GP-FUEL | 1 | |
| 1162041 | 7 GUARD | 1 | |
| 1249325 | 8 SENSOR GP-FUEL LEVEL | 1 | |
| 1452817 | 9 HOSE AS | 1 | |
| 2287091 | 10 SEAL-O-RING | 1 | |
| 3008495 | 11 RECEIVER (FAST FILL FUEL) | 1 | |
| 3047982 | 12 VALVE AS-MANUAL | 1 | |
| 6V8358 | VALVE-BALL (MANUAL SHUTOFF) | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 4L6454 | 13 BOLT (3/8-16X1-IN) | 6 | |
| 6V9831 | 14 CAP (ORFS) | 1 | |
| 8C6873 | 15 CONNECTOR | 1 | |
| 8T2501 | 16 BOLT (3/8-16X2-IN) | 4 | |
| 8T4896 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 9M7958 | 18 CLAMP-HOSE | 1 | |
| 5T8645 | KIT-VENT (FUEL TANK)(ALUMINUM) | 1 | |
| 2721595 | KIT-VENT (FUEL TANK)(PLASTIC) | 1 |
