System And Components
359-4575 TANK GP-FUELS/N DMC1-UP
Group No: 359-4575
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G0244 | 1 GAUGE GP-FUEL LEVEL | 1 | |
| 3E7753 | 2 FLOAT AS | 1 | |
| 6G7803 | 3 VENT AS | 1 | |
| 8M3368 | 4 VALVE-CHECK | 1 | |
| 3884327 | 5 CAP-DUST | 1 | |
| 1162041 | 6 GUARD | 1 | |
| 1249325 | 7 SENSOR GP-FUEL LEVEL | 1 | |
| 1452817 | 8 HOSE AS | 1 | |
| 3761308 | 10 RECEIVER AS (FAST FILL FUEL) | 1 | |
| 2525806 | 11 VALVE AS-SHUTOFF (FAST FILL FUEL) | 1 | |
| 3408819 | 12 VENT AS | 1 | |
| 3594600 | 13 HOSE AS | 1 | |
| 3607440 | 14 TANK GP-FUEL | 1 | |
| 1J9671 | 16 SEAL-O-RING | 2 | |
| 1P4582 | 17 FLANGE-HALF | 2 | |
| 3047982 | 18 VALVE AS-MANUAL | 1 | |
| 6V8358 | VALVE-BALL (MANUAL SHUTOFF) | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3J5389 | 19 PLUG (EXTERNAL) | 1 | |
| 4J0527 | 21 SEAL-O-RING | 1 | |
| 4L6454 | 22 BOLT (3/8-16X1-IN) | 6 | |
| 5P2618 | 24 CONNECTOR | 2 | |
| 8T2501 | 25 BOLT (3/8-16X2-IN) | 4 | |
| 8T4223 | 29 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4896 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 8T4184 | 31 BOLT (M12X1.75X45-MM) | 4 | |
| 9M7958 | 32 CLAMP-HOSE | 1 | |
| 5T8645 | KIT-VENT (FUEL TANK) | 1 | |
| 2721595 | KIT-VENT (FUEL TANK) | 1 |
