System And Components
437-1337 LINES GP-HOISTS/N D3T189-UP
Group No: 437-1337
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P1295 | 1 HOSE (21-CM EACH) | ||
| 1630593 | 2 TUBE AS | 1 | |
| 1728681 | 3 CLIP | 2 | |
| 1749708 | 4 ADAPTER-FILTER | 1 | |
| 1866317 | 5 MANIFOLD GP-HYDRAULIC (HOIST) | 2 | |
| 1P4582 | 6 FLANGE-HALF | 8 | |
| 2094575 | 7 CLAMP | 8 | |
| 2313944 | 8 PLATE | 1 | |
| 2343544 | 9 SEAL-O-RING | 4 | |
| 2881033 | 10 TUBE AS | 1 | |
| 2938192 | 11 HOSE AS | 1 | |
| 3196240 | 12 CONNECTOR AS | 3 | |
| 6V9873 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3198961 | 13 HOSE AS | 1 | |
| 3199575 | 14 HOSE AS | 1 | |
| 3216569 | 15 PLATE | 1 | |
| 3218614 | 16 ELBOW AS | 1 | |
| 8T7521 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3293356 | 17 NUT (M12X1.75-THD) | 5 | |
| 3309766 | 18 ELBOW AS | 1 | |
| 8T7970 | ELBOW | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3445674 | 19 NUT (M8X1.25-THD) | 2 | |
| 3445675 | 20 NUT (M10X1.5-THD) | 1 | |
| 3565705 | 21 VALVE GP-CONTROL | 1 | |
| 3727914 | 22 HOSE AS | 1 | |
| 3778722 | 23 PLATE AS | 1 | |
| 3996643 | 24 HOSE AS | 1 | |
| 4196292 | 25 TUBE AS | 1 | |
| 4196293 | 26 TUBE AS | 1 | |
| 4196294 | 27 TUBE AS | 1 | |
| 4196295 | 28 TUBE AS | 1 | |
| 3196220 | 29 ELBOW AS | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 4792171 | 30 BOLT AS | 2 | |
| 4883974 | 31 BOLT AS | 2 | |
| 4T6788 | 32 FILTER-OIL (ADVANCED EFFICIENCY) | 1 | |
| 2237809 | FILTER-OIL (ULTRA HIGH EFFICIENCY) | 1 | |
| 5C9762 | 33 MANIFOLD | 1 | |
| 5P1076 | 34 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5P7468 | 35 CLIP (SLOT) | 1 | |
| 5P7469 | 36 CLIP (TAB) | 1 | |
| 5P8444 | 37 GROMMET (37-MM ID) | 1 | |
| 6E5472 | 38 SCREEN GP (HOIST LINES) | 2 | |
| 0083214 | RING-RETAINING (INTERNAL) | 1 | |
| 9T1364 | KIT-SCREEN | 1 | |
| 6V1572 | 39 CLIP (SLOT) | 2 | |
| 6V1573 | 40 CLIP (TAB) | 2 | |
| 6V1574 | 41 GROMMET | 2 | |
| 6V4590 | 42 SEAL-O-RING | 8 | |
| 6V5039 | 43 CLIP (SLOT) | 1 | |
| 6V5040 | 44 CLIP (TAB) | 1 | |
| 7X2549 | 45 BOLT (M12X1.75X100-MM) | 6 | |
| 8T0568 | 46 SEAL-O-RING | 4 | |
| 8T4121 | 47 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4122 | 48 WASHER-HARD (17X32X3.5-MM THK) | 5 | |
| 8T4139 | 49 BOLT (M12X1.75X30-MM) | 3 | |
| 8T4176 | 50 BOLT (M12X1.75X90-MM) | 6 | |
| 8T4184 | 51 BOLT (M12X1.75X45-MM) | 9 | |
| 8T4185 | 52 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4193 | 53 BOLT (M16X2X50-MM) | 5 | |
| 8T4223 | 54 WASHER-HARD (13.5X25.5X3-MM THK) | 25 | |
| 8T4224 | 55 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T6870 | 56 BOLT (M8X1.25X70-MM) | 2 | |
| 8X9217 | 57 HOSE AS | 1 |
