System And Components
132-2048 VALVE GP-CONTROL -HOISTS/N 1HW1-UP
Group No: 132-2048
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1U0323 | 1 PLUG AS | 3 | |
| 1U0322 | 1A BUSHING | 1 | |
| 3P9498 | 2 PLUG-ORIFICE | 1 | |
| 6E5066 | 4 SCREEN (HYDRAULIC)(HOIST/AUX CONTROL VALVE) | 1 | |
| 6J3380 | 5 SPRING | 1 | |
| 7J7423 | 6 VALVE-CONTROL | 3 | |
| 8B4624 | 7 SHIM (0.032-IN THK) | 7 | |
| 8B4624 | 7A SHIM (0.032-IN THK) | 4 | |
| 8J2379 | 8 VALVE-RELIEF (BRAKE COOLING RELIEF) | 1 | |
| 1067683 | 9 ADAPTER | 1 | |
| 1138263 | 10 PISTON | 1 | |
| 1185081 | 11 ACTUATOR GP-PILOT CONTROL (HOIST/AUXILIARY) | 2 | |
| 1266612 | 12 BODY | 1 | |
| 1322049 | 14 BODY | 1 | |
| 1322051 | 15 VALVE GP-RELIEF (HOIST) | 1 | |
| 1327102 | 17 VALVE GP-COUNTERBALANCE (HOIST/AUXILIARY) | 1 | |
| 1621492 | 19 CONNECTOR | 1 | |
| 0304606 | 20 SEAL-O-RING | 1 | |
| 1266104 | 21 PLUG | 1 | |
| 1488407 | 22 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3893709 | 23 PLUG AS | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3603682 | PLUG-O-RING | 1 | |
| 3985596 | 24 PLUG AS | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 3893708 | 25 PLUG AS | 6 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3985604 | 26 PLUG AS | 2 | |
| 2385078 | SEAL-O-RING | 1 | |
| 3603675 | PLUG (5/16-24-THD) | 1 | |
| 3960393 | 27 PLUG AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 | |
| 1P3709 | 28 SEAL-RECTANGULAR | 1 | |
| 1P4578 | 29 FLANGE-HALF | 8 | |
| 1P4579 | 30 FLANGE-HALF | 4 | |
| 1P4582 | 31 FLANGE-HALF | 2 | |
| 1P4584 | 32 FLANGE-HALF | 4 | |
| 2S4078 | 33 SEAL-O-RING | 3 | |
| 3D4603 | 34 PLUG-PIPE | 1 | |
| 3K6113 | 35 WASHER-HARD (12X18.5X3-MM THK) | 4 | |
| 4H5232 | 36 PIN-SPRING | 3 | |
| 4J0522 | 37 SEAL-O-RING | 1 | |
| 4J0523 | 38 SEAL-O-RING | 1 | |
| 4J0527 | 39 SEAL-O-RING | 1 | |
| 5H6005 | 40 SEAL-O-RING | 1 | |
| 5P2566 | 41 BOLT (1/2-13X1.5-IN) | 12 | |
| 5P6300 | 42 SEAL-O-RING | 1 | |
| 6K6307 | 43 SEAL-O-RING | 1 | |
| 6V4432 | 44 BOLT (1/2-13X4-IN) | 4 | |
| 6V7418 | 45 PLUG-PIPE | 2 | |
| 6V8676 | 46 SEAL-O-RING | 1 | |
| 7B7525 | 47 BOLT-SOCKET HEAD (7/16-14X1.25-IN) | 4 | |
| 7S8491 | 48 SPRING | 3 | |
| 7X0293 | 49 BOLT (3/8-16X4.75-IN) | 2 | |
| 7X0301 | 50 BOLT (3/8-16X7-IN) | 2 | |
| 7X0335 | 51 BOLT (1/2-13X5.25-IN) | 5 | |
| 7X0584 | 52 WASHER-HARD (13.5X20.5X2-MM THK) | 7 | |
| 8T4223 | 53 WASHER-HARD (13.5X25.5X3-MM THK) | 24 | |
| 8T5360 | 54 WASHER (12X22.5X2.5-MM THK) | 16 | |
| 8T8916 | 55 BOLT (7/16-14X1.5-IN) | 16 | |
| 8T8919 | 56 BOLT (1/2-13X1.75-IN) | 8 | |
| 8T8920 | 57 BOLT (1/2-13X3.25-IN) | 4 | |
| 9P8217 | 58 WASHER (10X14.68X1.65-MM THK) | 4 | |
| 3886987 | 59 SHIM (0.4-MM THK) | 2 | |
| 6E5283 | KIT-SEAL (HOIST/AUX CONTROL VALVE) | 1 |
