Assembly
100%

174-6567 CAB GPS/N 5AZ264-UP

Group No: 174-6567
Part NumberPart NameQty
3V46941 PLUG-BUTTON8
4P74812 SPACER (6.6X25X21-MM THK)2
6V85473 PLUG-BUTTON3
6V89284 HOOK-COAT1
8T54015 PLUG-BUTTON2
9U82636 COVER1
11466587 WASHER (6.5X17X1-MM THK)54
13700028 CAB GP (ROPS)1
13700939 PLATE AS1
9X2032NUT-WELD (M4X0.7-THD)16
141331510 DASH GP1
141516011 PANEL1
141516112 PANEL1
141516213 PANEL1
141516314 PANEL1
141516415 PANEL1
257700716 COVER (LH)1
257700817 COVER (RH)1
141516718 COVER (LH)1
141516819 COVER (RH)1
141516920 WASHER (7.5X40X3-MM THK)10
141517021 COVER2
141517122 COVER1
257702123 COVER2
141517324 COVER (LH)1
141517425 COVER (RH)1
141864826 COVER-TRIM1
143945327 SEAL1
144410728 FASTENER10
144411029 TRAY AS1
161260530 HANDLE (GRAB)1
5T431531 HANDRAIL1
176531232 HOLDER-CUP1
254515733 LINER AS-CAB1
1460897FASTENER-PANEL11
254515834 COVER-ACCESS1
3E802035 SCREW-TRUSS HEAD (M6X1X25-MM)2
4L645436 BOLT (3/8-16X1-IN)2
5M306237 BOLT (3/8-16X0.75-IN)12
6V132238 BOLT (1/4-20X0.375-IN)10
5P411539 WASHER-HARD (7.2X19X2-MM THK)10
8T422340 WASHER-HARD (13.5X25.5X3-MM THK)2
8T489641 WASHER-HARD (10.2X18.5X2.5-MM THK)14
8T938342 BOLT (1/2-13X0.75-IN)2
9X203843 WASHER (7X19X2-MM THK)13
9X204244 SCREW-TRUSS HEAD (M6X1X12-MM)57
9X204545 SCREW-TRUSS HEAD (M6X1X20-MM)7
9X204646 SCREW-TRUSS HEAD (M6X1X35-MM)4
5P567347 SEAL (1.2-M)
5P567347A SEAL (0.2-M EACH)
5P567347B SEAL (0.3-M EACH)
8T937148 BOLT (3/8-16X0.5-IN)2
5P575549 SEAL (0.1-M EACH)
