System And Components
163-4540 LINES GP-REAR ATTACHMENT -PULLED UNITS/N 2PZ106-UP
Group No: 163-4540
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C9762 | 1 MANIFOLD | 1 | |
| 6E5471 | 2 SCREEN GP (PULLED UNIT) | 1 | |
| 9T1364 | KIT-SCREEN | 1 | |
| 0083214 | RING-RETAINING (INTERNAL) | 1 | |
| 6V3965 | 3 FITTING (QUICK DISCONNECT) | 1 | |
| 7I5937 | 4 HOSE AS | 1 | |
| 8W5179 | 5 ADAPTER | 1 | |
| 1322048 | 6 VALVE GP-CONTROL | 1 | |
| 1866317 | 7 MANIFOLD GP-HYDRAULIC (HOIST) | 1 | |
| 1620094 | 8 BLOCK | 1 | |
| 1630593 | 9 TUBE AS | 1 | |
| 1630594 | 10 TUBE AS | 1 | |
| 1642477 | 11 HOSE AS | 1 | |
| 1642480 | 12 HOSE AS | 1 | |
| 1642481 | 13 HOSE AS | 1 | |
| 1642486 | 14 HOSE AS | 1 | |
| 1P4579 | 15 FLANGE-HALF | 4 | |
| 1P4582 | 16 FLANGE-HALF | 8 | |
| 1P4584 | 17 FLANGE-HALF | 2 | |
| 1P4585 | 18 FLANGE-HALF | 2 | |
| 2H6338 | 19 SEAL-O-RING | 1 | |
| 3J1907 | 20 SEAL-O-RING | 7 | |
| 4J0524 | 21 SEAL-O-RING | 3 | |
| 4J0527 | 22 SEAL-O-RING | 5 | |
| 5K3294 | 23 CLIP | 2 | |
| 5P2566 | 24 BOLT (1/2-13X1.5-IN) | 4 | |
| 5S2256 | 25 BOLT (1/2-13X1.75-IN) | 4 | |
| 6J2680 | 26 SEAL-O-RING | 2 | |
| 6J3134 | 27 SEAL-O-RING | 1 | |
| 6V0852 | 28 CAP-DUST | 1 | |
| 6V8189 | 29 NUT (5/16-18-THD) | 2 | |
| 6V8397 | 30 SEAL-O-RING | 3 | |
| 6V8398 | 31 SEAL-O-RING | 4 | |
| 6V8724 | 32 ELBOW | 1 | |
| 6V9850 | 33 ELBOW | 1 | |
| 6V9873 | 34 CONNECTOR | 3 | |
| 7X0274 | 35 BOLT (5/16-18X2.75-IN) | 2 | |
| 7X0328 | 36 BOLT (1/2-13X3.5-IN) | 6 | |
| 7X0346 | 37 BOLT (5/8-11X2-IN) | 8 | |
| 7X0347 | 38 BOLT (5/8-11X2.25-IN) | 1 | |
| 8T4122 | 39 WASHER-HARD (17X32X3.5-MM THK) | 9 | |
| 8T4223 | 40 WASHER-HARD (13.5X25.5X3-MM THK) | 30 | |
| 8T4224 | 41 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T7521 | 42 ELBOW | 1 | |
| 8T8919 | 43 BOLT (1/2-13X1.75-IN) | 16 | |
| 8T9389 | 44 BOLT (1/2-13X2.75-IN) | 4 | |
| 9S4191 | 45 PLUG (9/16-18-THD) | 1 |
