System And Components
162-3309 LINES GP-HOISTS/N 2BW636-1982
Group No: 162-3309
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C9762 | 1 MANIFOLD | 1 | |
| 5P9560 | 2 UNION | 2 | |
| 6E5471 | 3 SCREEN GP (HOIST LINES) | 2 | |
| 9T1364 | KIT-SCREEN | 1 | |
| 0083214 | RING-RETAINING (INTERNAL) | 1 | |
| 8W9962 | 5 HOSE AS | 2 | |
| 1078140 | 6 HOSE AS | 1 | |
| 1620094 | 7 BLOCK | 1 | |
| 1623300 | 8 HOSE AS | 1 | |
| 1623301 | 9 HOSE AS | 1 | |
| 3104072 | 10 HOSE AS | 1 | |
| 3104071 | 11 HOSE AS | 1 | |
| 1623305 | 12 HOSE AS | 1 | |
| 1623306 | 13 HOSE AS | 1 | |
| 1623307 | 14 HOSE AS | 1 | |
| 1623308 | 15 HOSE AS | 1 | |
| 1630593 | 16 TUBE AS | 1 | |
| 1866317 | 17 MANIFOLD GP-HYDRAULIC (HOIST) | 2 | |
| 2194694 | 18 HOSE AS | 1 | |
| 2451661 | 19 VALVE GP-CONTROL | 1 | |
| 2881033 | 20 TUBE AS | 1 | |
| 2977968 | 21 FITTING | 2 | |
| 2977969 | 22 CAP-DUST | 2 | |
| 1728681 | 23 CLIP | 2 | |
| 1P4579 | 24 FLANGE-HALF | 4 | |
| 1P4582 | 25 FLANGE-HALF | 10 | |
| 1P4584 | 26 FLANGE-HALF | 4 | |
| 3D2824 | 27 SEAL-O-RING | 4 | |
| 3J1907 | 28 SEAL-O-RING | 6 | |
| 4J0522 | 29 SEAL-O-RING | 8 | |
| 4J0524 | 30 SEAL-O-RING | 4 | |
| 4J0527 | 31 SEAL-O-RING | 8 | |
| 5P2566 | 32 BOLT (1/2-13X1.5-IN) | 16 | |
| 5S2256 | 33 BOLT (1/2-13X1.75-IN) | 4 | |
| 6J2680 | 34 SEAL-O-RING | 5 | |
| 6J3134 | 35 SEAL-O-RING | 2 | |
| 6V8189 | 37 NUT (5/16-18-THD) | 2 | |
| 6V8397 | 38 SEAL-O-RING | 3 | |
| 6V8398 | 39 SEAL-O-RING | 4 | |
| 6V9001 | 40 ELBOW | 1 | |
| 6V9850 | 41 ELBOW | 1 | |
| 6V9873 | 42 CONNECTOR | 3 | |
| 7G3413 | 43 CLIP (SLOT) | 1 | |
| 7G3414 | 44 CLIP (TAB) | 1 | |
| 7G3415 | 45 GROMMET | 1 | |
| 7X0274 | 46 BOLT (5/16-18X2.75-IN) | 2 | |
| 7X0328 | 47 BOLT (1/2-13X3.5-IN) | 12 | |
| 7X0346 | 48 BOLT (5/8-11X2-IN) | 5 | |
| 8T4122 | 49 WASHER-HARD (17X32X3.5-MM THK) | 5 | |
| 8T4223 | 50 WASHER-HARD (13.5X25.5X3-MM THK) | 42 | |
| 8T4224 | 51 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T7521 | 52 ELBOW | 1 | |
| 8T8917 | 53 BOLT (1/2-13X1.25-IN) | 2 | |
| 8T8919 | 54 BOLT (1/2-13X1.75-IN) | 12 | |
| 9S4191 | 55 PLUG (9/16-18-THD) | 1 |
