System And Components
153-2088 LINES GP-HOISTS/N 4GZ1-UP
Group No: 153-2088
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C9762 | 1 MANIFOLD | 1 | |
| 6V0852 | 2 CAP-DUST | 2 | |
| 6V3965 | 3 FITTING (QUICK DISCONNECT) | 2 | |
| 8X4575 | 4 FILTER AS-BREATHER (HOIST LINES) | 1 | |
| 8X5568 | 5 HOSE AS | 2 | |
| 9M0164 | 6 CLAMP-HOSE | 1 | |
| 1357792 | 7 HOSE AS | 2 | |
| 1583403 | 8 MANIFOLD GP-HYDRAULIC (HOIST LINES) | 2 | |
| 1630593 | 9 TUBE AS | 1 | |
| 1630594 | 10 TUBE AS | 1 | |
| 1670692 | 11 HOSE AS | 1 | |
| 1255619 | 12 HOSE AS | 1 | |
| 1255621 | 13 HOSE AS | 1 | |
| 1357654 | 14 HOSE AS | 1 | |
| 1357655 | 15 HOSE AS | 1 | |
| 1466174 | 16 HOSE AS | 2 | |
| 1470997 | 17 VALVE GP-CONTROL (HOIST)(HOIST) | 1 | |
| 1P4579 | 18 FLANGE-HALF | 8 | |
| 1P4582 | 19 FLANGE-HALF | 12 | |
| 1P4584 | 20 FLANGE-HALF | 8 | |
| 1S0994 | 21 CLIP (LOOP) | 1 | |
| 2S4078 | 22 SEAL-O-RING | 1 | |
| 3J1907 | 23 SEAL-O-RING | 8 | |
| 3K0360 | 24 SEAL-O-RING | 1 | |
| 4J0522 | 25 SEAL-O-RING | 8 | |
| 4J0524 | 26 SEAL-O-RING | 4 | |
| 4J0527 | 27 SEAL-O-RING | 8 | |
| 5C7261 | 28 NUT (M8X1.25-THD) | 2 | |
| 5K3294 | 29 CLIP | 2 | |
| 5K9090 | 30 SEAL-O-RING | 2 | |
| 6E5472 | 31 SCREEN GP (HOIST LINES) | 2 | |
| 9T1364 | KIT-SCREEN | 1 | |
| 0083214 | RING-RETAINING (INTERNAL) | 1 | |
| 6J2680 | 32 SEAL-O-RING | 4 | |
| 6J3134 | 33 SEAL-O-RING | 2 | |
| 6V0397 | 34 FLANGE-HALF | 16 | |
| 6V8397 | 35 SEAL-O-RING | 2 | |
| 6V8398 | 36 SEAL-O-RING | 4 | |
| 6V8636 | 37 CONNECTOR | 1 | |
| 6V9008 | 38 ELBOW (90-DEG) | 1 | |
| 6V9873 | 39 CONNECTOR | 3 | |
| 6V9875 | 40 CONNECTOR | 1 | |
| 7G3413 | 41 CLIP (SLOT) | 1 | |
| 7G3414 | 42 CLIP (TAB) | 1 | |
| 7G3415 | 43 GROMMET | 1 | |
| 7M8485 | 44 SEAL-O-RING | 1 | |
| 7X7729 | 45 WASHER (11X25X3-MM THK) | 2 | |
| 8T4121 | 46 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4122 | 47 WASHER-HARD (17X32X3.5-MM THK) | 5 | |
| 8T4137 | 48 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4176 | 49 BOLT (M12X1.75X90-MM) | 12 | |
| 8T4183 | 50 BOLT (M12X1.75X40-MM) | 64 | |
| 8T4184 | 51 BOLT (M12X1.75X45-MM) | 16 | |
| 8T4193 | 52 BOLT (M16X2X50-MM) | 5 | |
| 8T4196 | 53 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 54 WASHER-HARD (13.5X25.5X3-MM THK) | 92 | |
| 8T4224 | 55 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T6685 | 56 BOLT (M10X1.5X110-MM) | 2 | |
| 8T6870 | 57 BOLT (M8X1.25X70-MM) | 2 | |
| 8T7521 | 58 ELBOW | 1 | |
| 8X5569 | 59 HOSE AS | 1 | |
| 8X5570 | 60 HOSE AS | 1 | |
| 8X6483 | 61 BASE AS | 1 | |
| 9S4185 | 62 PLUG (3/4-16-THD) | 1 | |
| 9S4191 | 63 PLUG (9/16-18-THD) | 1 |
