System And Components
151-2711 TORQUE CONVERTER GPS/N 5RT1-359
Group No: 151-2711
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1T1098 | 1 GEAR-PUMP DRIVE (62-TEETH) | 1 | |
| 1T1209 | 2 CARRIER-RING (SEAL) | 1 | |
| 1T1232 | 3 RING-RETAINING | 2 | |
| 1T1235 | 4 CAM-FREEWHEEL | 1 | |
| 1T1244 | 5 WASHER (SPLIT) | 4 | |
| 1T1247 | 6 SLEEVE-WEAR | 1 | |
| 1T1248 | 7 SLEEVE-WEAR | 1 | |
| 1T1254 | 8 WASHER (SPLIT) | 2 | |
| 1T1257 | 9 SPRING | 2 | |
| 1T1258 | 10 RING-SNAP | 1 | |
| 1T1566 | 11 BEARING-THRUST | 1 | |
| 1T1646 | 12 PLATE | 2 | |
| 1T1754 | 13 ROLLER-FREEWHEEL | 22 | |
| 1T1819 | 14 CARRIER-CLUTCH | 1 | |
| 1T1821 | 15 CARRIER-RING | 1 | |
| 1T1832 | 16 CARRIER-STATOR | 1 | |
| 1T1855 | 17 RACE-FREEWHEEL | 1 | |
| 1T1897 | 18 PLATE-CLUTCH | 2 | |
| 1T1899 | 19 PISTON-LOCKUP CLUTCH | 1 | |
| 1T1925 | 20 GASKET (FLAT) | 1 | |
| 1T1982 | 21 PLATE-BACKING | 1 | |
| 1T2007 | 22 DISTRIBUTOR-FLUID | 1 | |
| 1T2042 | 23 SLEEVE | 1 | |
| 1T2043 | 24 RACE-THRUST BEARING | 1 | |
| 3P1669 | 25 RETAINER (SHAFT) | 1 | |
| 3P9497 | 26 PLUG-ORIFICE (7/16-27-THD) | 1 | |
| 5P4055 | 27 BEARING-THRUST | 1 | |
| 5P6408 | 28 BEARING-INNER | 1 | |
| 6Y6370 | 29 RING-SEAL | 2 | |
| 1303639 | 30 SLEEVE | 1 | |
| 1303640 | 31 RACE-THRUST BEARING | 1 | |
| 1410408 | 32 PILOT-FLYWHEEL | 1 | |
| 1410409 | 33 PLATE-RETAINER | 1 | |
| 1415950 | 34 CAGE-ROLLER | 1 | |
| 1463092 | 35 HUB AS (IMPELLER) | 1 | |
| 1T2044 | PIN-THRUST RACE | 2 | |
| 1465831 | 36 HUB AS (TURBINE) | 1 | |
| 1T1253 | 36A BUSHING | 1 | |
| 1T2044 | PIN-THRUST RACE | 2 | |
| 1482968 | 37 TURBINE | 1 | |
| 1482972 | 38 STATOR-CONVERTER | 1 | |
| 1501145 | 39 IMPELLER AS | 1 | |
| 1580426 | 40 YOKE | 1 | |
| 1882595 | 41 RING-SNAP | 1 | |
| 1906013 | 42 SHAFT-OUTPUT | 1 | |
| 1906014 | 43 HUB-CLUTCH | 1 | |
| 2144677 | 44 WASHER-HARD (17X27X5-MM THK) | 24 | |
| 2239743 | 45 SEAL-LIP TYPE | 1 | |
| 2864365 | 46 DISC-FRICTION | 3 | |
| 3201236 | 47 HOUSING-ROTATING | 1 | |
| 0S1589 | 48 BOLT (5/8-11X1.75-IN) | 24 | |
| 0S1594 | 49 BOLT (3/8-16X1-IN) | 8 | |
| 0S1595 | 50 BOLT (1/2-13X1.25-IN) | 12 | |
| 1135945 | 51 RING-SEAL | 2 | |
| 1281663 | 52 RING-SEAL | 2 | |
| 1410410 | 53 WASHER-SPRING (76X127X10.5-MM THK) | 1 | |
| 1695861 | 54 PLUG AS | 2 | |
| 3K8460 | PLUG (1/2-20-THD) | 1 | |
| 5P7814 | SEAL-O-RING | 1 | |
| 1B4367 | 55 BOLT (5/8-11X3-IN) | 1 | |
| 1T0720 | 56 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 8 | |
| 1T1365 | 57 CARRIER-RING | 1 | |
| 2B2695 | 58 BOLT (5/16-18X0.875-IN) | 6 | |
| 3B1915 | 59 BOLT (3/8-16X1.375-IN) | 11 | |
| 3D4603 | 60 PLUG-PIPE | 1 | |
| 3H5368 | 61 BOLT (7/16-14X1.375-IN) | 24 | |
| 3L1824 | 62 BALL BEARING | 1 | |
| 3S1284 | 63 RING-SEAL | 1 | |
| 3519430 | 64 BOLT (3/8-16X0.5-IN) | 12 | |
| 5H2824 | 65 SEAL-O-RING | 1 | |
| 5M2894 | 66 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 5P2546 | 67 BOLT-12 POINT HEAD (7/16-14X1.25-IN) | 12 | |
| 5P8244 | 68 WASHER-HARD (12X22.5X2.5-MM THK) | 24 | |
| 5P8245 | 69 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 7L3385 | 70 SEAL-O-RING | 1 | |
| 8M2031 | 71 BALL BEARING | 1 | |
| 8S3373 | 72 RING-SEAL | 1 | |
| 9S8008 | 73 PLUG (1-1/16-12-THD) | 1 | |
| 9X8873 | 74 BOLT (1/2-13X2.25-IN) | 3 |
