System And Components
163-4536 LINES GP-HOISTS/N APX1-405
Group No: 163-4536
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C9762 | 1 MANIFOLD | 1 | |
| 6E5471 | 2 SCREEN GP (HOIST LINES) | 2 | |
| 9T1364 | KIT-SCREEN | 1 | |
| 0083214 | RING-RETAINING (INTERNAL) | 1 | |
| 6V3480 | 3 FITTING-GREASE | 2 | |
| 6V3482 | 4 CAP AS | 2 | |
| 8W5179 | 5 ADAPTER | 2 | |
| 8W9962 | 6 HOSE AS | 2 | |
| 1322048 | 7 VALVE GP-CONTROL (HOIST) | 1 | |
| 1620094 | 8 BLOCK | 1 | |
| 1630593 | 9 TUBE AS | 1 | |
| 1630594 | 10 TUBE AS | 1 | |
| 1642477 | 11 HOSE AS | 1 | |
| 1642478 | 12 HOSE AS | 1 | |
| 1642479 | 13 HOSE AS | 1 | |
| 1642480 | 14 HOSE AS | 1 | |
| 1642481 | 15 HOSE AS | 1 | |
| 1642482 | 16 HOSE AS | 1 | |
| 1642483 | 17 HOSE AS | 1 | |
| 1642484 | 18 HOSE AS | 1 | |
| 1642485 | 19 HOSE AS | 1 | |
| 1642486 | 20 HOSE AS | 1 | |
| 1645563 | 21 UNION AS | 2 | |
| 5P9560 | UNION | 1 | |
| 3D2824 | SEAL-O-RING | 2 | |
| 1645567 | 23 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1866317 | 24 MANIFOLD GP-HYDRAULIC (HOIST) | 2 | |
| 1488367 | 25 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488378 | 26 ELBOW AS | 1 | |
| 6V8724 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1488407 | 27 PLUG AS | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1504043 | 28 CONNECTOR AS | 3 | |
| 6V9873 | CONNECTOR | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1P4578 | 29 FLANGE-HALF | 16 | |
| 1P4579 | 30 FLANGE-HALF | 8 | |
| 1P4582 | 31 FLANGE-HALF | 12 | |
| 1P4584 | 32 FLANGE-HALF | 8 | |
| 4J0522 | 33 SEAL-O-RING | 8 | |
| 4J0524 | 34 SEAL-O-RING | 6 | |
| 4J0527 | 35 SEAL-O-RING | 8 | |
| 5K3294 | 36 CLIP | 2 | |
| 5P2566 | 37 BOLT (1/2-13X1.5-IN) | 8 | |
| 5S2256 | 38 BOLT (1/2-13X1.75-IN) | 4 | |
| 6J2680 | 39 SEAL-O-RING | 5 | |
| 6J3134 | 40 SEAL-O-RING | 2 | |
| 6V0852 | 41 CAP-DUST | 2 | |
| 6V8189 | 42 NUT (5/16-18-THD) | 2 | |
| 7G3413 | 43 CLIP (SLOT) | 1 | |
| 7G3414 | 44 CLIP (TAB) | 1 | |
| 7G3415 | 45 GROMMET | 1 | |
| 7X0274 | 46 BOLT (5/16-18X2.75-IN) | 2 | |
| 7X0328 | 47 BOLT (1/2-13X3.5-IN) | 12 | |
| 7X0346 | 48 BOLT (5/8-11X2-IN) | 5 | |
| 8T4122 | 49 WASHER-HARD (17X32X3.5-MM THK) | 5 | |
| 8T4223 | 50 WASHER-HARD (13.5X25.5X3-MM THK) | 62 | |
| 8T4224 | 51 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T5360 | 52 WASHER (12X22.5X2.5-MM THK) | 32 | |
| 8T8916 | 53 BOLT (7/16-14X1.5-IN) | 32 | |
| 8T8917 | 54 BOLT (1/2-13X1.25-IN) | 2 | |
| 8T8919 | 55 BOLT (1/2-13X1.75-IN) | 32 | |
| 8T9389 | 56 BOLT (1/2-13X2.75-IN) | 8 | |
| 1743181 | 57 ELBOW AS | 1 | |
| 8T7521 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 3J1907 | SEAL-O-RING | 1 |
