System And Components
163-4536 LINES GP-HOISTS/N APX1-UP
Group No: 163-4536
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C9762 | 1 MANIFOLD | 1 | |
| 6E5471 | 2 SCREEN GP (HOIST LINES) | 2 | |
| 9T1364 | KIT-SCREEN | 1 | |
| 0083214 | RING-RETAINING (INTERNAL) | 1 | |
| 8W9962 | 7 HOSE AS | 2 | |
| 1630593 | 9 TUBE AS | 1 | |
| 2881033 | 10 TUBE AS | 1 | |
| 1642481 | 11 HOSE AS | 1 | |
| 1642482 | 12 HOSE AS | 1 | |
| 1642483 | 13 HOSE AS | 1 | |
| 1642486 | 14 HOSE AS | 1 | |
| 1743181 | 17 ELBOW AS | 1 | |
| 8T7521 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1866317 | 18 MANIFOLD GP-HYDRAULIC (HOIST)(HOIST) | 2 | |
| 2451662 | 19 VALVE GP-CONTROL (HOIST) | 1 | |
| 1642484 | 20 HOSE AS | 1 | |
| 1642485 | 21 HOSE AS | 1 | |
| 2556921 | 22 HOSE AS | 1 | |
| 2556922 | 23 HOSE AS | 1 | |
| 2556923 | 24 HOSE AS | 1 | |
| 2556924 | 25 HOSE AS | 1 | |
| 1488367 | 26 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488378 | 27 ELBOW AS | 1 | |
| 6V8724 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1488407 | 28 PLUG AS | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1504043 | 29 CONNECTOR AS | 3 | |
| 6V9873 | CONNECTOR | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1P4582 | 32 FLANGE-HALF | 10 | |
| 4J0522 | 34 SEAL-O-RING | 8 | |
| 4J0524 | 35 SEAL-O-RING | 4 | |
| 4J0527 | 36 SEAL-O-RING | 8 | |
| 1728681 | 37 CLIP | 2 | |
| 5P2566 | 38 BOLT (1/2-13X1.5-IN) | 6 | |
| 6J2680 | 40 SEAL-O-RING | 6 | |
| 6J3134 | 41 SEAL-O-RING | 2 | |
| 6V8189 | 42 NUT (5/16-18-THD) | 2 | |
| 7G3413 | 43 CLIP (SLOT) | 1 | |
| 7G3414 | 44 CLIP (TAB) | 1 | |
| 7G3415 | 45 GROMMET | 1 | |
| 7X0274 | 46 BOLT (5/16-18X2.75-IN) | 2 | |
| 7X0328 | 47 BOLT (1/2-13X3.5-IN) | 12 | |
| 7X0346 | 48 BOLT (5/8-11X2-IN) | 5 | |
| 8T4122 | 49 WASHER-HARD (17X32X3.5-MM THK) | 5 | |
| 8T4223 | 50 WASHER-HARD (13.5X25.5X3-MM THK) | 26 | |
| 8T4224 | 51 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T8917 | 54 BOLT (1/2-13X1.25-IN) | 2 | |
| 8T8919 | 55 BOLT (1/2-13X1.75-IN) | 6 | |
| 4168232 | 57 PLATE | 1 | |
| 4392172 | 58 PLATE AS | 1 | |
| 1F0748 | NUT-WELD (1/2-13-THD) | 5 | |
| 5C6565 | 59 BOLT (1/2-13X1.125-IN) | 5 | |
| 5P1076 | 60 WASHER-HARD (13.5X30X4-MM THK) | 5 | |
| 1620094 | 61 BLOCK | 1 | |
| 5S2256 | 62 BOLT (1/2-13X1.75-IN) | 4 | |
| 3D8908 | 63 COVER | 1 |
