System And Components
421-8573 LINES GP-POWER TRAIN OIL -CHASSISS/N SSP1041-1060
Group No: 421-8573
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P1293 | 1 HOSE (18-CM EACH) | ||
| 6V0852 | 2 CAP-DUST | 1 | |
| 2218571 | 3 CLAMP | 8 | |
| 8W3166 | 4 HOSE AS | 1 | |
| 1241859 | 5 SEAL-O-RING | 2 | |
| 1355353 | 6 BLOCK | 1 | |
| 1724211 | 7 SPACER (10.5X22X50.8-MM THK) | 1 | |
| 1749708 | 8 ADAPTER-FILTER | 1 | |
| 1973295 | 9 FLANGE-HALF | 6 | |
| 2343544 | 10 SEAL-O-RING | 8 | |
| 4392336 | 11 HOSE AS | 1 | |
| 2958668 | 12 HOSE AS | 1 | |
| 4286633 | 13 HOSE AS | 1 | |
| 4392335 | 14 HOSE AS | 1 | |
| 2958676 | 15 TUBE AS | 1 | |
| 2958677 | 16 TUBE AS | 1 | |
| 2958678 | 17 TUBE AS | 1 | |
| 2958745 | 18 BLOCK | 1 | |
| 3001334 | 19 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 3012197 | 20 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3182330 | 21 TUBE AS | 1 | |
| 3195383 | 22 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3200389 | 23 PLATE | 1 | |
| 3201317 | 24 PLATE AS | 1 | |
| 3202122 | 25 HOSE AS | 1 | |
| 3206134 | 26 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3755402 | 27 HOSE AS | 1 | |
| 3218617 | 28 CONNECTOR AS | 1 | |
| 8T8985 | CONNECTOR | 1 | |
| 2287095 | SEAL-O-RING | 1 | |
| 2287096 | SEAL-O-RING | 1 | |
| 3717151 | 29 ELBOW AS | 1 | |
| 8T1682 | ELBOW | 1 | |
| 2287095 | SEAL-O-RING | 1 | |
| 2385086 | SEAL-O-RING | 1 | |
| 3309758 | 30 ELBOW AS | 1 | |
| 8T4149 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3309759 | 31 TEE AS | 1 | |
| 4I7651 | TEE-O-RING PORT | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3309764 | 32 ELBOW AS | 1 | |
| 8C6712 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3351812 | 33 HOSE AS | 1 | |
| 3351814 | 34 TUBE AS | 1 | |
| 3399704 | 35 FILTER GP-OIL (TRANSMISSION) | 1 | |
| 3399704 | 35A FILTER GP-OIL (TORQUE CONVERTER CHARGING) | 1 | |
| 4285400 | 36 HOSE AS | 1 | |
| 3416252 | 37 HOSE AS | 1 | |
| 3416253 | 38 HOSE AS | 1 | |
| 4285396 | 39 HOSE AS | 1 | |
| 3755400 | 40 HOSE AS | 1 | |
| 2815871 | 41 ADAPTER | 1 | |
| 4285385 | 42 PLATE AS | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 4593182 | 43 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 0950670 | 44 BOLT (M12X1.75X45-MM) | 4 | |
| 1308433 | 45 GROMMET | 2 | |
| 1336934 | 46 SPACER (11X20X25-MM THK) | 2 | |
| 1645567 | 47 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1912962 | 48 SEAL-O-RING | 3 | |
| 1P4579 | 49 FLANGE-HALF | 16 | |
| 1P4584 | 50 FLANGE-HALF | 4 | |
| 2352476 | 51 SEAL-RECTANGULAR | 1 | |
| 2352479 | 52 SEAL-RECTANGULAR | 1 | |
| 2501424 | 54 ELBOW AS | 1 | |
| 6V8724 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2815979 | 55 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3410086 | 57 ELBOW AS | 1 | |
| 8C3364 | ELBOW | 1 | |
| 2287094 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3196227 | 58 ELBOW AS | 1 | |
| 6V9851 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3196240 | 59 CONNECTOR AS | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3218649 | 60 VALVE AS-FLUID SAMPLING | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 8T0077 | 61 CONNECTOR | 1 | |
| 3260316 | 62 PLUG AS | 1 | |
| 9S6130 | PLUG | 1 | |
| 2287096 | SEAL-O-RING | 1 | |
| 3309762 | 63 FITTING AS | 1 | |
| 0857356 | ELBOW-ADAPTER | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 4T6788 | 64 FILTER-OIL (ADVANCED EFFICIENCY)(COOLER LINES) | 1 | |
| 2237809 | FILTER-OIL (ULTRA HIGH EFFICIENCY) | 1 | |
| 5P7466 | 65 CLIP (SLOT) | 3 | |
| 5P7467 | 66 CLIP (TAB) | 3 | |
| 5P7468 | 67 CLIP (SLOT) | 1 | |
| 5P7469 | 68 CLIP (TAB) | 1 | |
| 5P7470 | 69 CLIP (SLOT) | 8 | |
| 5P7471 | 70 CLIP (TAB) | 8 | |
| 5P7703 | 71 GROMMET (52-MM ID) | 3 | |
| 5P8112 | 72 GROMMET | 3 | |
| 5P8182 | 73 GROMMET (46-MM ID) | 5 | |
| 5P8444 | 74 GROMMET (37-MM ID) | 1 | |
| 6D4244 | 75 CLIP (LOOP) | 5 | |
| 6V1249 | 76 GROMMET (22-MM ID) | 1 | |
| 6V4356 | 78 CLIP (SLOT) | 2 | |
| 6V4357 | 79 CLIP (TAB) | 2 | |
| 6V4590 | 80 SEAL-O-RING | 3 | |
| 5P7464 | 81 CLIP (SLOT) | 1 | |
| 5P7465 | 82 CLIP (TAB) | 1 | |
| 7X2550 | 83 BOLT (M12X1.75X110-MM) | 4 | |
| 7X2554 | 84 BOLT (M16X2X70-MM) | 10 | |
| 7X3392 | 85 WASHER-HARD (13.5X22.5X3-MM THK) | 12 | |
| 8C3447 | 86 CAP-DUST | 1 | |
| 8T0568 | 87 SEAL-O-RING | 2 | |
| 8T4121 | 88 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4133 | 89 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 90 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4139 | 91 BOLT (M12X1.75X30-MM) | 17 | |
| 8T4182 | 92 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4183 | 93 BOLT (M12X1.75X40-MM) | 31 | |
| 8T4184 | 94 BOLT (M12X1.75X45-MM) | 14 | |
| 8T4191 | 95 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4195 | 96 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 97 WASHER-HARD (13.5X25.5X3-MM THK) | 85 | |
| 8T4244 | 98 NUT (M12X1.75-THD) | 1 | |
| 8T4648 | 99 BOLT (M12X1.75X70-MM) | 8 | |
| 8T4910 | 100 BOLT (M12X1.75X60-MM) | 4 | |
| 8T4956 | 101 BOLT (M12X1.75X35-MM) | 14 | |
| 8T5005 | 102 BOLT (M10X1.5X70-MM) | 1 | |
| 8T5041 | 103 BOLT (M12X1.75X120-MM) | 4 | |
| 8T7338 | 104 BOLT (M16X2X45-MM) | 8 | |
| 9X8257 | 105 WASHER (17.5X30X3.5-MM THK) | 20 | |
| 6V9833 | 106 CAP | 1 | |
| 1488431 | 107 TEE AS | 1 | |
| 6V8785 | TEE | 1 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 2815941 | 108 CONNECTOR AS | 1 | |
| 8T7496 | CONNECTOR | 1 | |
| 2154639 | SEAL-O-RING | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 3833587 | 109 HOSE AS | 1 | |
| 2977976 | 110 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4285380 | 111 PLATE | 2 | |
| 2287090 | 112 SEAL-O-RING | 1 | |
| 2385080 | 114 SEAL-O-RING | 2 | |
| 2815972 | 115 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 4285404 | 116 BLOCK | 4 | |
| 4285406 | 117 BLOCK | 4 |
