System And Components
291-6877 CONTROL GP-AIR STARTINGS/N ERM1-162
Group No: 291-6877
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G0233 | 1 BRACKET | 1 | |
| 3D7587 | 2 ELBOW | 2 | |
| 5B8978 | 3 TEE | 1 | |
| 5D6998 | 4 HORN GP-AIR | 1 | |
| 5F5434 | 5 VALVE AS-VENT (AIR START) | 1 | |
| 5F5434 | 5A VALVE AS-VENT (AUTOLUBE) | 1 | |
| 5P4426 | 6 ELBOW-AIR BRAKE | 2 | |
| 7D5208 | 7 FITTING (QUICK DISCONNECT, FEMALE) | 1 | |
| 8M3368 | 8 VALVE-CHECK | 1 | |
| 8R0721 | 9 SPACER (11X16X35-MM THK) | 1 | |
| 9M7357 | 10 COUPLING AS | 1 | |
| 9X3495 | 11 CLIP AS | 1 | |
| 1415746 | 12 SENSOR GP-PRESSURE (AIR SYSTEM) | 1 | |
| 1850008 | 13 VALVE GP-SOLENOID (24-VOLT)(AIR HORN) | 1 | |
| 1941986 | 14 AIR DRYER GP | 1 | |
| 1962876 | 15 TUBE | 1 | |
| 2081628 | 16 ELBOW AS | 1 | |
| 2T1922 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 2219576 | 17 VALVE GP-SOLENOID (24-VOLT)(AIR STARTING) | 1 | |
| 2219576 | 17A VALVE GP-SOLENOID (24-VOLT)(AUTOLUBE ACTUATION) | 1 | |
| 2219578 | KIT-VALVE | 1 | |
| 2933516 | 18 HOSE AS | 1 | |
| 2958715 | 19 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 2958716 | 20 HOSE AS | 1 | |
| 2968255 | 21 HOSE AS | 1 | |
| 2981975 | 23 HOSE AS | 1 | |
| 2981976 | 24 HOSE AS | 1 | |
| 2981977 | 25 HOSE AS | 1 | |
| 2981979 | 26 HOSE AS | 1 | |
| 2981980 | 27 HOSE AS | 1 | |
| 2994904 | 28 HOSE AS | 1 | |
| 3001359 | 29 PLATE | 1 | |
| 3012185 | 30 PLATE | 1 | |
| 3028496 | 31 CONNECTOR | 1 | |
| 3047474 | 32 PLATE | 1 | |
| 3066622 | 33 HOSE AS | 1 | |
| 3076602 | 34 PLATE AS | 1 | |
| 3512419 | 35 PUMP GP-LUBRICATION | 1 | |
| 3375229 | 36 HOSE AS | 1 | |
| 0026454 | 37 CONNECTOR | 1 | |
| 0080728 | 38 FITTING (CLOSE) | 1 | |
| 0308370 | 39 ADAPTER-PIPE | 1 | |
| 0444101 | 40 COUPLING-PIPE | 1 | |
| 1095605 | 41 ADAPTER-PIPE | 2 | |
| 1600980 | 42 BLOCK | 1 | |
| 1694279 | 43 CONNECTOR AS | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8C6872 | CONNECTOR | 1 | |
| 1S0994 | 44 CLIP (LOOP) | 1 | |
| 2Y4062 | 45 ADAPTER | 1 | |
| 3B6553 | 46 ELBOW | 1 | |
| 3B8822 | 47 ELBOW | 1 | |
| 3E7448 | 48 CONNECTOR | 1 | |
| 4D0124 | 49 ELBOW | 1 | |
| 4D2560 | 50 CONNECTOR-PIPE | 2 | |
| 4D3734 | 51 ELBOW | 2 | |
| 4H6147 | 52 CONNECTOR | 5 | |
| 4N3411 | 53 VALVE GP-RELAY (AIR STARTING MOTOR) | 1 | |
| 5C2890 | 54 NUT (M6X1-THD) | 2 | |
| 5H4778 | 55 ELBOW | 7 | |
| 5P1076 | 56 WASHER-HARD (13.5X30X4-MM THK) | 10 | |
| 5P7854 | 57 CLIP (LOOP) | 1 | |
| 5P8753 | 58 TEE | 1 | |
| 5P8998 | 59 FITTING (1/4-18-THD) | 1 | |
| 5S7349 | 60 BOLT (1/4-20X0.5-IN) | 2 | |
| 6B9664 | 61 VALVE-AIR RELIEF | 1 | |
| 5240073 | VALVE-AIR RELIEF | 1 | |
| 6D4244 | 62 CLIP (LOOP) | 4 | |
| 6K1019 | 63 NIPPLE-PIPE | 1 | |
| 7D5206 | 64 CAP-DUST | 1 | |
| 7G8839 | 65 SPACER (13.5X57X6-MM THK) | 2 | |
| 7T8331 | 66 MOUNT AS | 2 | |
| 7X2535 | 67 BOLT (M6X1X60-MM) | 2 | |
| 7X7655 | 68 VALVE AS-DRAIN (AIR TANK) | 1 | |
| 8B2664 | 69 BUSHING-REDUCER | 1 | |
| 8B9913 | 70 ELBOW-REDUCING | 1 | |
| 8D4755 | 71 REGULATOR | 1 | |
| 8T4121 | 72 WASHER-HARD (11X21X2.5-MM THK) | 37 | |
| 8T4133 | 73 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 74 BOLT (M10X1.5X25-MM) | 15 | |
| 8T4137 | 75 BOLT (M10X1.5X20-MM) | 25 | |
| 8T4183 | 76 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4184 | 77 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4205 | 78 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T4896 | 80 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8T4910 | 81 BOLT (M12X1.75X60-MM) | 2 | |
| 8T4956 | 82 BOLT (M12X1.75X35-MM) | 4 | |
| 8T6466 | 83 BOLT (M10X1.5X60-MM) | 1 | |
| 8T9364 | 84 BOLT (1/4-20X0.625-IN) | 2 | |
| 9B7237 | 85 BOLT (3/8-16X1.25-IN) | 2 | |
| 9M8406 | 86 CLIP (LOOP) | 36 | |
| 9X6165 | 87 WASHER (6.5X22X2.5-MM THK) | 2 | |
| 9X8256 | 88 WASHER (6.6X12X2-MM THK) | 2 | |
| 6D3479 | 89 CLIP (LOOP) | 1 | |
| 8T7934 | 90 WASHER-HARD (11X21X5-MM THK) | 1 | |
| 7C5105 | KIT-VALVE SEAL (AIR STARTING) | 1 | |
| 4590644 | KIT-VALVE REPAIR | 1 |
