System And Components
284-5820 LUBRICATION GP-AUTOMATICS/N ERM1-269
Group No: 284-5820
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5T2125 | 1 ANGLE | 2 | |
| 8W9338 | 2 HOSE AS | 1 | |
| 1173719 | 3 HOSE AS | 1 | |
| 1502083 | 4 HOSE AS | 1 | |
| 1643492 | 5 HOSE AS | 1 | |
| 2962827 | 6 HOSE AS | 1 | |
| 2994866 | 7 HOSE AS | 1 | |
| 2994867 | 8 HOSE AS | 1 | |
| 2994870 | 9 HOSE AS | 1 | |
| 2994871 | 10 HOSE AS | 1 | |
| 2994877 | 11 HOSE AS | 1 | |
| 2994878 | 12 HOSE AS | 1 | |
| 2999413 | 13 HOSE AS | 2 | |
| 2999414 | 14 HOSE AS | 2 | |
| 3068961 | 15 PLATE AS | 1 | |
| 3068970 | 16 HOSE AS | 1 | |
| 3068971 | 17 HOSE AS | 1 | |
| 3110321 | 18 HOSE AS | 1 | |
| 3139243 | 19 HOSE AS | 2 | |
| 3139249 | 20 PLATE AS | 1 | |
| 3139250 | 21 PLATE AS | 1 | |
| 3195206 | 22 PLATE | 2 | |
| 3285390 | 23 HOSE AS | 2 | |
| 3285391 | 24 HOSE AS | 1 | |
| 3285392 | 25 HOSE AS | 1 | |
| 3295848 | 26 HOSE AS | 1 | |
| 3324032 | 27 HOSE AS | 1 | |
| 3328659 | 28 HOSE AS | 1 | |
| 3329229 | 29 HOSE AS | 1 | |
| 3526492 | 30 TEE AS | 1 | |
| 0815645 | TEE | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3526493 | 31 ELBOW AS | 3 | |
| 2T2396 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3526494 | 32 ADAPTER AS | 8 | |
| 8C6865 | CONNECTOR | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3526495 | 33 TEE AS | 1 | |
| 8T6895 | TEE-UNION | 1 | |
| 2287090 | SEAL-O-RING | 3 | |
| 3526496 | 34 ADAPTER AS | 3 | |
| 8C6871 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3526497 | 35 ADAPTER AS | 2 | |
| 8T6776 | ADAPTER | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3526504 | 36 ELBOW AS | 34 | |
| 7X0492 | ELBOW | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 0020639 | 37 ADAPTER-PIPE | 8 | |
| 6V1867 | 38 CLIP (SLOT) | 1 | |
| 6V1868 | 39 CLIP (TAB) | 1 | |
| 1984777 | 40 WASHER-HARD (11X25X10-MM THK) | 4 | |
| 1S1015 | 41 CLIP (LOOP) | 1 | |
| 2R1939 | 42 CLIP (LOOP) | 2 | |
| 3269712 | 43 SPACER (11.4X25.4X35-MM THK) | 2 | |
| 3309774 | 44 UNION AS | 1 | |
| 6V8995 | UNION (STRAIGHT) | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3328542 | 45 TEE AS | 2 | |
| 6V9844 | TEE-SWIVEL | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 3J5390 | 46 PLUG (3/8-18-THD) | 4 | |
| 4D6466 | 47 CLIP | 16 | |
| 5K3294 | 48 CLIP | 1 | |
| 5N8396 | 49 NIPPLE-PIPE | 2 | |
| 5P1076 | 50 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 6D3479 | 51 CLIP (LOOP) | 41 | |
| 6D4244 | 52 CLIP (LOOP) | 30 | |
| 6D4636 | 53 CLIP (LOOP) | 2 | |
| 3602052 | 54 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 6V9169 | 55 NUT (13/16-16-THD) | 2 | |
| 7D7233 | 56 CLIP (LOOP) | 1 | |
| 7X7729 | 57 WASHER (11X25X3-MM THK) | 8 | |
| 8T4121 | 58 WASHER-HARD (11X21X2.5-MM THK) | 93 | |
| 8T4133 | 59 NUT (M10X1.5-THD) | 6 | |
| 8T4136 | 60 BOLT (M10X1.5X25-MM) | 10 | |
| 8T4137 | 61 BOLT (M10X1.5X20-MM) | 67 | |
| 8T4195 | 62 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4196 | 63 BOLT (M10X1.5X35-MM) | 8 | |
| 8T4956 | 64 BOLT (M12X1.75X35-MM) | 4 | |
| 8T6466 | 65 BOLT (M10X1.5X60-MM) | 2 |
