Assembly
100%

349-3370 PIPE GP-EXHAUST -FIELD INSTALLEDS/N SPD1-170

Group No: 349-3370
Part NumberPart NameQty
5T27621 SPRING2
5T33672 ELBOW2
6G70313 ELBOW1
6G70384 RING-SEAL2
8X32335 PISTON2
8X32536 LOCK6
34933727 BRACKET AS1
34933758 TUBE AS1
35175949 PLATE8
364848810 PLATE8
364849711 PLATE AS2
3558941NUT-WELD (M16X2-THD)2
364849812 PLATE AS1
364849913 PLATE AS1
367360914 GUARD AS1
092552415 BOLT (M12X1.75X80-MM)2
136418216 BOLT (M16X2X100-MM)8
267882117 WASHER (17X36X12-MM THK)36
278046018 BOLT (M16X2X120-MM)6
332003519 ROD-THREADED (M16X2X150-MM)4
5P107620 WASHER-HARD (13.5X30X4-MM THK)6
6V424821 BOLT (M10X1.5X25-MM)12
6V814922 NUT (M12X1.75-THD)2
7X772923 WASHER (11X25X3-MM THK)12
8T412124 WASHER-HARD (11X21X2.5-MM THK)12
8T413225 NUT (M16X2-THD)14
8T417926 BOLT (M12X1.75X20-MM)6
8T419327 BOLT (M16X2X50-MM)8
8T419528 BOLT (M10X1.5X30-MM)12
8T733829 BOLT (M16X2X45-MM)4
