System And Components
192-5745 LINES GP-AIR STARTINGS/N JSM1-UP; 5YW1-UP
Group No: 192-5745
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1Y0413 | 1 TEE | 1 | |
| 2H9091 | 2 CONNECTOR-PIPE | 2 | |
| 3B6552 | 3 ELBOW-PIPE | 1 | |
| 3D7587 | 4 ELBOW | 1 | |
| 5F5434 | 6 VALVE AS-VENT | 1 | |
| 5L5502 | 7 FITTING | 1 | |
| 5T7116 | 8 HOSE AS | 1 | |
| 7K1181 | 9 STRAP-CABLE | 1 | |
| 9D4049 | 10 HORN GP-AIR | 1 | |
| 9G9150 | 11 CLIP | 2 | |
| 9X3495 | 12 CLIP AS | 1 | |
| 8C3334 | RIVET-TUBULAR | 2 | |
| 0332177 | 13 TEE-PIPE | 2 | |
| 1558253 | 14 WIRE AS | 1 | |
| 1606348 | 15 HOSE AS | 1 | |
| 2174184 | 16 VALVE AS-CONTROL | 1 | |
| 2179957 | 17 PLATE AS | 1 | |
| 2187262 | 18 HOSE AS | 1 | |
| 2187269 | 19 HOSE AS | 3 | |
| 2187276 | 20 HOSE AS | 1 | |
| 2187277 | 21 HOSE AS | 1 | |
| 2187278 | 22 HOSE AS | 1 | |
| 2187279 | 23 HOSE AS | 1 | |
| 2187280 | 24 HOSE AS | 1 | |
| 2187281 | 25 HOSE AS | 1 | |
| 2187285 | 26 HOSE AS | 1 | |
| 2187286 | 27 HOSE AS | 1 | |
| 2187470 | 28 HOSE AS | 1 | |
| 2220570 | 29 VALVE GP-RELIEF (AIR START LINES) | 1 | |
| 0026453 | 30 ELBOW | 2 | |
| 0026454 | 31 CONNECTOR | 1 | |
| 0308370 | 32 ADAPTER-PIPE | 1 | |
| 3B7262 | 33 NIPPLE-PIPE | 1 | |
| 0S1615 | 34 BOLT (1/4-20X0.75-IN) | 2 | |
| 1305300 | 35 CLIP | 1 | |
| 1415746 | 36 SENSOR GP-PRESSURE (AIR START LINES) | 1 | |
| 1591010 | 37 BRACKET | 1 | |
| 1591011 | 38 PLATE | 1 | |
| 1600980 | 39 BLOCK | 1 | |
| 1664341 | 40 HARNESS AS-WIRING | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 7R2750 | SEAL-CONNECTOR | 2 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 9X1813 | SLEEVE (18-CM) | ||
| 1962412 | TERMINAL AS (16-GA) | 2 | |
| 1018106 | LOCK-CONNECTOR | 1 | |
| 1018108 | PLUG-CONNECTOR | 1 | |
| 1L8432 | 41 FITTING | 1 | |
| 3550211 | 42 AIR DRYER AS (AIR STARTING) | 2 | |
| 1075869 | CARTRIDGE-DESICCANT | 1 | |
| 1215897 | VALVE GP-PURGE | 1 | |
| 1432677 | VALVE-AIR RELIEF | 1 | |
| 2H3940 | 43 ELBOW | 4 | |
| 3E7448 | 44 CONNECTOR | 1 | |
| 3J7354 | 45 SEAL-O-RING | 1 | |
| 3S8666 | 46 ELBOW | 1 | |
| 4D3734 | 47 ELBOW | 2 | |
| 4D6466 | 48 CLIP | 2 | |
| 4H6147 | 49 CONNECTOR | 4 | |
| 4S7606 | 50 ELBOW | 4 | |
| 5H4778 | 51 ELBOW | 6 | |
| 5M6213 | 52 PLUG-PIPE (1/4-18-THD) | 1 | |
| 5P0537 | 53 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5P1076 | 54 WASHER-HARD (13.5X30X4-MM THK) | 11 | |
| 5N2840 | 55 CLIP | 1 | |
| 5T4434 | 56 VALVE AS-SOLENOID (AUTOLUBE SYSTEM) | 1 | |
| 5D5569 | CONNECTOR | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9737 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 5T6374 | 57 SPACER (11X20X40-MM THK) | 3 | |
| 6D4244 | 58 CLIP (LOOP) | 1 | |
| 6K1019 | 59 NIPPLE-PIPE | 1 | |
| 6V3940 | 60 BOLT (M8X1.25X25-MM) | 1 | |
| 6V7981 | 61 BOLT (M10X1.5X70-MM) | 3 | |
| 6V8359 | 62 BOLT (M6X1X70-MM) | 2 | |
| 7D5206 | 63 CAP-DUST (AIR LINES) | 1 | |
| 7D5207 | 64 PLUG | 1 | |
| 7D5208 | 65 FITTING (QUICK DISCONNECT, FEMALE) | 1 | |
| 7T9074 | 66 VALVE GP-SOLENOID (24-VOLT)(HORN) | 1 | |
| 8D4765 | 67 REGULATOR | 1 | |
| 8D9423 | 68 COUPLING | 1 | |
| 8T4121 | 69 WASHER-HARD (11X21X2.5-MM THK) | 28 | |
| 8T4136 | 70 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 71 BOLT (M10X1.5X20-MM) | 22 | |
| 8T4183 | 72 BOLT (M12X1.75X40-MM) | 11 | |
| 8T5066 | 73 BOLT (M6X1X60-MM) | 4 | |
| 9M8406 | 74 CLIP (LOOP) | 14 | |
| 9X8267 | 75 WASHER (6.6X12X2-MM THK) | 6 | |
| 3S2093 | 76 STRAP-CABLE | 1 | |
| 4D0124 | 77 ELBOW | 1 | |
| 8T4222 | 78 WASHER-PLATED (11X32X2.5-MM THK) | 1 | |
| 5S7379 | 79 BOLT (3/8-16X0.875-IN) | 2 | |
| 7J8611 | 80 ELBOW-PIPE | 1 | |
| 8T6764 | 81 PLUG-PIPE (1/8-27-THD) | 1 | |
| 1160118 | 82 CLIP | 2 | |
| 1215899 | KIT-MOUNTING BRACKET (AIR DRYER) | 1 | |
| 2239706 | KIT-VALVE (AIR DRYER) | 1 | |
| 3550251 | KIT-CHECK VALVE (AIR DRYER) | 1 |
