System And Components
Assembly
100%

139-5907 ACTUATOR GP-POWER -CRANKCASE, POWER TRAINS/N BXD1-599

Group No: 139-5907
Part NumberPart NameQty
7K11811 STRAP-CABLE6
9X67722 STRAP-CABLE3
14439613 HARNESS AS-POWER (GUARD)1
1552270KIT-CONNECTING PLUG (2-PIN)1
1552271KIT-CONNECTING PLUG (4-PIN)1
8T8737PLUG-SEAL1
8T41374 BOLT (M10X1.5X20-MM)1
15713565 SWITCH AS-TOGGLE (POWER TRAIN GUARD ACTUATOR)1
9G3695PLUG-SEAL2
1028806KIT-RECEPTACLE (8-PIN)1
3E3389WEDGE-RECEPTACLE LOCK (8-PIN)1
6T3631NUT-HEX (15/32-32-THD)2
6T3632LOCKWASHER1
6T3633RING-LOCKING1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)6
15713646 SWITCH AS-TOGGLE (CRANKCASE GUARD ACTUATOR)1
3E3383WEDGE-RECEPTACLE LOCK (6-PIN)1
6T3631NUT-HEX (15/32-32-THD)2
6T3632LOCKWASHER1
6T3633RING-LOCKING1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)6
1028805KIT-RECEPTACLE (6-PIN)1
19673297 ACTUATOR GP-POWER (POWER TRAIN GUARD)2
9W0852PIN-CONNECTOR (14-GA TO 16-GA)2
1028802KIT-RECEPTACLE (2-PIN)1
3B46288 PIN-COTTER8
3W92269 PIN4
8M277010 CLIP (LOOP)1
8T412111 WASHER-HARD (11X21X2.5-MM THK)1
152874912 PLATE-INSTRUCTION1
