System And Components
299-1066 VALVE & MTG GP-BRAKES/N RBT165-171
Group No: 299-1066
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3409729 | 1 VALVE GP-CHECK (PILOT) | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 6V0852 | 2 CAP-DUST | 3 | |
| 3409727 | 3 VALVE GP-CHECK | 1 | |
| 1759106 | 4 ELBOW AS | 1 | |
| 6V9001 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2863226 | 5 CLAMP AS | 6 | |
| 3017429 | 7 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 7 | |
| 3017434 | 8 TUBE AS | 1 | |
| 3258574 | 9 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 12 | |
| 3289974 | 10 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3309732 | 11 ADAPTER AS | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3309760 | 12 COUPLING AS | 1 | |
| 4I6140 | COUPLING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3309768 | 13 TEE AS | 2 | |
| 8C4082 | TEE | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3353971 | 14 TEE AS | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 2213494 | SEAL-O-RING | 2 | |
| 3353972 | 15 TEE AS | 1 | |
| 1584307 | TEE-UNION | 1 | |
| 2287092 | SEAL-O-RING | 2 | |
| 2287093 | SEAL-O-RING | 1 | |
| 3353973 | 16 TEE AS | 1 | |
| 8C6515 | TEE | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3353974 | 17 FITTING AS | 1 | |
| 7W7381 | FITTING-OUTLET | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3353978 | 20 CONNECTOR AS | 2 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3116686 | CONNECTOR | 1 | |
| 3353979 | 21 ADAPTER AS | 1 | |
| 8C3051 | ADAPTER | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3501355 | 22 HOSE AS | 1 | |
| 2360779 | 23 HOSE AS | 1 | |
| 4357991 | 24 TUBE AS | 1 | |
| 1645567 | 25 COUPLER AS-QUICK DISCONNECT (MALE) | 3 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1984778 | 26 WASHER-HARD (13.5X30X12-MM THK) | 16 | |
| 2147568 | 27 SEAL-O-RING | 1 | |
| 2287089 | 28 SEAL-O-RING | 1 | |
| 2287093 | 29 SEAL-O-RING | 1 | |
| 2443712 | 30 PLUG AS | 2 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2681605 | 31 ELBOW AS | 1 | |
| 8T1686 | ADAPTER-ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2815933 | 32 ELBOW AS | 1 | |
| 6V9853 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2977976 | 33 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3072670 | 34 PLUG AS | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3159836 | 35 CONNECTOR AS | 1 | |
| 8T8898 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3196212 | 36 CONNECTOR AS | 1 | |
| 6V8714 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3196220 | 37 ELBOW AS | 1 | |
| 6V9008 | ELBOW | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3196235 | 38 TEE AS | 1 | |
| 6V9847 | TEE-SWIVEL | 1 | |
| 2287093 | SEAL-O-RING | 2 | |
| 3218657 | 39 ELBOW AS | 3 | |
| 6V8076 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3295511 | 40 ELBOW AS | 2 | |
| 6V8723 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 5P4116 | 41 WASHER-HARD (8.8X20.5X2-MM THK) | 12 | |
| 5P7468 | 42 CLIP (SLOT) | 1 | |
| 5P7469 | 43 CLIP (TAB) | 1 | |
| 8T4121 | 44 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 45 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4183 | 46 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4189 | 47 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4192 | 48 BOLT (M12X1.75X25-MM) | 4 | |
| 8T4223 | 49 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 8T4244 | 50 NUT (M12X1.75-THD) | 4 | |
| 8T4908 | 51 BOLT (M8X1.25X25-MM) | 8 | |
| 8T4910 | 52 BOLT (M12X1.75X60-MM) | 4 | |
| 8T8902 | 53 ADAPTER-TEE | 1 | |
| 8T9518 | 54 GROMMET (24-MM ID) | 1 | |
| 9X6639 | 55 FITTING-ORIFICE | 1 | |
| 3869566 | 56 TUBE AS | 1 | |
| 3159837 | 57 ELBOW AS | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 4321817 | 58 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 3196213 | 59 CONNECTOR AS | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 8T4956 | 60 BOLT (M12X1.75X35-MM) | 3 |
