System And Components
453-5289 LINES GP-FUELPART OF 383-7682 CONVERSION AR-ENGINE
Group No: 453-5289
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3872 | 1 SUPPORT | 2 | |
| 2L6055 | 2 CAP-PIPE | 1 | |
| 3E2343 | 3 TEE | 1 | |
| 4196617 | 4 TUBE AS | 1 | |
| 6L7322 | 5 TEE-PIPE | 1 | |
| 7X7951 | 6 ELBOW-UNION | 1 | |
| 8T2657 | 7 JOINT AS-TUBE | 2 | |
| 9X7529 | SEAL | 1 | |
| 4190893 | 8 VALVE GP-SOLENOID (24-VOLT)(GAS SHUTOFF) | 1 | |
| 2102007 | 9 REGULATOR GP-GAS PRESSURE | 1 | |
| 2107769 | 10 PLATE | 1 | |
| 2308986 | 11 BRACKET | 1 | |
| 2370927 | 12 WASHER-BEVEL | 4 | |
| 2385080 | 13 SEAL-O-RING | 1 | |
| 4205122 | 14 TUBE AS | 1 | |
| 2655255 | 15 PLATE | 1 | |
| 2938396 | 16 CORE AS-FUEL COOLER | 1 | |
| 8T6764 | PLUG-PIPE (1/8-27-THD) | 1 | |
| 3307378 | 17 TUBE AS | 1 | |
| 3307379 | 18 TUBE AS | 1 | |
| 3307380 | 19 TUBE AS | 1 | |
| 3441950 | 20 CLIP (SLOT) | 7 | |
| 4241117 | 21 BRACKET | 1 | |
| 4253549 | 22 GASKET | 2 | |
| 4517943 | 23 TUBE | 1 | |
| 4522248 | 24 GASKET | 2 | |
| 4533532 | 25 FLANGE-ADAPTER | 1 | |
| 4616844 | 26 BRACKET | 1 | |
| 0444101 | 27 COUPLING-PIPE | 1 | |
| 0L2070 | 28 BOLT (3/8-16X2.25-IN) | 1 | |
| 1653929 | 29 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1625 | 30 BOLT (5/8-11X2.5-IN) | 2 | |
| 1228905 | 31 ELBOW (90-DEG) | 1 | |
| 1A2029 | 32 BOLT (3/8-16X1.125-IN) | 4 | |
| 1A5822 | 33 BOLT (1/2-13X2.75-IN) | 4 | |
| 1B4367 | 35 BOLT (5/8-11X3-IN) | 6 | |
| 2287090 | 36 SEAL-O-RING | 1 | |
| 3441951 | 37 CLIP (TAB) | 7 | |
| 3B1915 | 38 BOLT (3/8-16X1.375-IN) | 8 | |
| 3B7286 | 39 NIPPLE-PIPE | 2 | |
| 3J5389 | 40 PLUG (EXTERNAL) | 1 | |
| 4K0367 | 41 NUT-FULL (5/8-11-THD) | 16 | |
| 4L9337 | 42 BOLT (3/8-16X1.5-IN) | 8 | |
| 5M2894 | 43 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 5P1075 | 44 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5P6446 | 45 BOLT-12 POINT HEAD (5/16-18X2-IN) | 3 | |
| 5P8247 | 46 WASHER-HARD (17X32X3.5-MM THK) | 32 | |
| 5S0003 | 47 NUT (5/16-18-THD) | 3 | |
| 6V8188 | 48 NUT (1/2-13-THD) | 4 | |
| 6V8398 | 49 SEAL-O-RING | 3 | |
| 6V8625 | 50 ELBOW | 1 | |
| 7X0325 | 51 BOLT (1/2-13X2.5-IN) | 4 | |
| 8T2502 | 52 BOLT (3/8-16X1.125-IN) | 4 | |
| 8T4223 | 53 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4896 | 54 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 9D6196 | 55 CLIP (SLOT) | 8 | |
| 9D6197 | 56 CLIP (TAB) | 8 | |
| 9M1974 | 57 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 9S8752 | 58 NUT-FULL (3/8-16-THD) | 10 | |
| 9X6138 | 59 PLUG-PIPE | 1 | |
| 9X6458 | 60 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 8S9092 | 61 BOLT (5/8-11X2.25-IN) | 8 | |
| 4208789 | 62 GASKET | 2 | |
| 9L9132 | 63 WASHER-HARD (10.2X25.5X2.5-MM THK) | 16 |
