System And Components
193-6296 LINES GP-HYDRAULICS/N FDB1906-2004
Group No: 193-6296
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V4356 | 1 CLIP (SLOT) | 1 | |
| 6V4357 | 2 CLIP (TAB) | 1 | |
| 8W5161 | 3 MANIFOLD | 1 | |
| 1986577 | 4 VALVE GP-SOLENOID & MANIFOLD | 1 | |
| 2476968 | 5 HOSE AS | 1 | |
| 2522317 | 6 PLATE AS | 1 | |
| 2527156 | 7 HOSE AS | 1 | |
| 2731168 | 8 HOSE AS | 1 | |
| 2731169 | 9 HOSE AS | 1 | |
| 2848944 | 10 HOSE AS | 1 | |
| 2995378 | 11 HOSE AS | 1 | |
| 3043288 | 12 HOSE AS | 1 | |
| 3095137 | 13 CONNECTOR AS | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 3218657 | 14 ELBOW AS | 1 | |
| 6V8076 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3295528 | 15 ELBOW AS | 1 | |
| 8T8899 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 4792172 | 16 BOLT AS | 3 | |
| 4883974 | 17 BOLT AS | 1 | |
| 4905465 | 18 HOSE AS | 1 | |
| 5252043 | 19 HOSE AS | 1 | |
| 1600012 | 20 CLIP (SLOT) | 1 | |
| 1600013 | 21 CLIP (TAB) | 1 | |
| 1645567 | 22 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2352474 | 23 SEAL-RECTANGULAR | 2 | |
| 2352476 | 24 SEAL-RECTANGULAR | 2 | |
| 2385082 | 25 SEAL-O-RING | 1 | |
| 2609221 | 26 ELBOW AS | 1 | |
| 9X2085 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2815972 | 27 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2815979 | 28 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 3196211 | 29 ADAPTER AS | 1 | |
| 2P8421 | ADAPTER-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3196219 | 30 ELBOW AS | 1 | |
| 6V9005 | ELBOW | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 3218652 | 31 TEE AS | 1 | |
| 6V9175 | TEE (FACE SEAL) | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 3293356 | 32 NUT (M12X1.75-THD) | 1 | |
| 3218616 | 33 FITTING AS | 1 | |
| 8X7851 | FITTING-ORIFICE | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3410103 | 34 CONNECTOR | 1 | |
| 3445675 | 35 NUT (M10X1.5-THD) | 2 | |
| 1P4582 | 36 FLANGE-HALF | 4 | |
| 1S1015 | 37 CLIP (LOOP) | 3 | |
| 3P2404 | 38 CLIP | 5 | |
| 4D7388 | 39 CLIP | 2 | |
| 5P7468 | 40 CLIP (SLOT) | 1 | |
| 5P7469 | 41 CLIP (TAB) | 1 | |
| 5P8077 | 42 FLANGE-HALF | 2 | |
| 5P8444 | 43 GROMMET (37-MM ID) | 1 | |
| 6D4244 | 44 CLIP (LOOP) | 2 | |
| 6V0400 | 45 FLANGE-HALF | 4 | |
| 6V0852 | 46 CAP-DUST | 1 | |
| 6V1867 | 47 CLIP (SLOT) | 3 | |
| 6V1868 | 48 CLIP (TAB) | 3 | |
| 6V1869 | 49 GROMMET (65-MM ID) | 3 | |
| 6V1875 | 50 GROMMET | 1 | |
| 6V4590 | 51 SEAL-O-RING | 2 | |
| 7X2544 | 52 BOLT (M10X1.5X140-MM) | 4 | |
| 8C8533 | 53 CLIP | 1 | |
| 8D9947 | 54 CLIP | 1 | |
| 8T4121 | 55 WASHER-HARD (11X21X2.5-MM THK) | 11 | |
| 8T4137 | 56 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4139 | 57 BOLT (M12X1.75X30-MM) | 3 | |
| 8T4184 | 58 BOLT (M12X1.75X45-MM) | 9 | |
| 8T4193 | 59 BOLT (M16X2X50-MM) | 4 | |
| 8T4196 | 60 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4223 | 61 WASHER-HARD (13.5X25.5X3-MM THK) | 21 | |
| 8T4956 | 62 BOLT (M12X1.75X35-MM) | 8 | |
| 8T5005 | 63 BOLT (M10X1.5X70-MM) | 2 | |
| 9X2646 | 64 CLIP (SLOT) | 1 | |
| 9X2647 | 65 CLIP (TAB) | 1 | |
| 9X8257 | 66 WASHER (17.5X30X3.5-MM THK) | 4 |
