System And Components
470-8606 WHEEL & BRAKE GPS/N GKG1-UP
Group No: 470-8606
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5B3265 | 1 GASKET | 2 | |
| 6B5262 | 2 PLUG | 1 | |
| 7I5617 | 3 SHIM PACK (INCLUDES 19-SHIMS) | 1 | |
| 8M3837 | 4 PLUG-MAGNETIC | 1 | |
| 8X2607 | 5 SHIM PACK (INCLUDES 20-SHIMS) | 2 | |
| 8X2608 | 6 PLATE | 1 | |
| 4954172 | 7 BEARING-CONE | 1 | |
| 9W7096 | 8 CUP-BEARING | 1 | |
| 1237270 | 9 SEAL-RING | 1 | |
| 1255938 | 10 WHEEL-FRONT | 1 | |
| 3847883 | 11 RETAINER | 1 | |
| 3847881 | 12 SPINDLE AS | 1 | |
| 3795785 | TUBE AS | 1 | |
| 4954171 | 13 BEARING-CONE | 1 | |
| 2903830 | 14 CUP-SPECIAL TAPERED | 1 | |
| 2920162 | 15 COVER | 1 | |
| 2994737 | 16 COVER | 1 | |
| 2994746 | 17 PLATE | 2 | |
| 3088498 | 18 PLATE | 1 | |
| 4218985 | 19 SEAL GP-DUO-CONE | 1 | |
| 5638599 | 20 SEAL GP-DUO-CONE | 1 | |
| 3144129 | 20A RING-TORIC | 2 | |
| 3462140 | 21 PLATE GP-AXLE IDENTIFICATION | 1 | |
| 3298934 | TAPE | ||
| 4438203 | 22 RETAINER | 1 | |
| 4708607 | 23 BRAKE GP-SERVICE & PARKING (FRONT) | 1 | |
| 1779755 | 24 BOLT (M30X3.5X160-MM) | 12 | |
| 1459278 | 25 BOLT (M20X2.5X90-MM) | 14 | |
| 8T6761 | 26 PLUG-PIPE (1-11-1/2 NPT THD) | 1 | |
| 3801397 | 27 SEAL-O-RING | 1 | |
| 4S5879 | 28 SEAL-O-RING | 1 | |
| 6V3689 | 29 SEAL-O-RING | 1 | |
| 6V3967 | 30 SEAL-O-RING | 1 | |
| 7X7729 | 31 WASHER (11X25X3-MM THK) | 6 | |
| 8M4436 | 32 SEAL-O-RING | 1 | |
| 8T3282 | 33 WASHER-HARD (22X35X3.5-MM THK) | 14 | |
| 8T4194 | 34 BOLT (M12X1.75X50-MM) | 12 | |
| 8T4196 | 35 BOLT (M10X1.5X35-MM) | 6 | |
| 8T4223 | 36 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 9X2199 | 37 BOLT (M30X3.5X50-MM) | 10 | |
| 9X7310 | 38 RING-SEAL | 1 | |
| 9X8399 | 39 WASHER (33X56X6-MM THK) | 12 | |
| 4438204 | 40 HUB-BRAKE | 1 |
