System And Components
366-3291 HANDRAIL GPS/N SSP1-UP
Group No: 366-3291
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1153580 | 1 PLATE | 1 | |
| 1953699 | 2 NUT (M8X1.25-THD) | 8 | |
| 2480102 | 3 U-BOLT (M8X1.25-THD) | 6 | |
| 2482221 | 4 HANDRAIL AS | 1 | |
| 2929302 | 5 PLATE | 4 | |
| 2482218 | 6 HANDRAIL AS | 1 | |
| 2980335 | 7 HANDRAIL AS | 1 | |
| 2980336 | 8 HANDRAIL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 16 | |
| 3003990 | 9 HANDRAIL AS (GATE) | 1 | |
| 3E8349 | SEAL | 5 | |
| 6F8480 | PLUG | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3004511 | 10 LATCH GP | 1 | |
| 3005351 | 11 PLATE | 1 | |
| 3093502 | 12 HANDRAIL AS | 1 | |
| 3093509 | 13 HANDRAIL AS | 1 | |
| 1463287 | 14 BOLT-SPECIAL | 2 | |
| 5C7261 | 15 NUT (M8X1.25-THD) | 4 | |
| 5P7468 | 16 CLIP (SLOT) | 6 | |
| 5P7469 | 17 CLIP (TAB) | 6 | |
| 8T4183 | 18 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4224 | 20 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4244 | 21 NUT (M12X1.75-THD) | 4 | |
| 8T7087 | 22 GROMMET (34-MM ID) | 6 | |
| 9X2133 | 23 HOSE (2-CM EACH) |
