System And Components
339-7924 COMPRESSOR GP-REFRIGERANTS/N B7B575-UP; WLR1-UP
Group No: 339-7924
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4649988 | 1 COMPRESSOR GP-REFRIGERANT | 1 | |
| 3298797 | 2 BELT TENSIONER | 1 | |
| 3331207 | 3 IDLER AS | 1 | |
| 2352484 | 4 SEAL-LIP TYPE | 1 | |
| 4711762 | 5 PULLEY AS | 1 | |
| 3008569 | PULLEY (8-GROOVE) | 1 | |
| 4652689 | SEAL-WEAR SLEEVE | 1 | |
| 3533976 | 6 BELT-SERPENTINE (AIR COMPRESSOR) | 1 | |
| 3725883 | 7 SUPPORT AS | 1 | |
| 2092086 | DOWEL | 2 | |
| 3397920 | SUPPORT | 1 | |
| 3397921 | 8 SUPPORT | 1 | |
| 3397922 | 9 GUARD AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 7 | |
| 3397923 | 10 GUARD | 1 | |
| 1327551 | 11 SPACER (11X19X6-MM THK) | 4 | |
| 1984765 | 12 WASHER-HARD (8.8X20X8-MM THK) | 4 | |
| 1984777 | 13 WASHER-HARD (11X25X10-MM THK) | 10 | |
| 1984767 | 14 WASHER-HARD (13.5X30X12-MM THK) | 4 | |
| 3160487 | 15 SPACER (11X25X70-MM THK) | 1 | |
| 8T4198 | 16 BOLT (M10X1.5X100-MM) | 1 | |
| 8T4195 | 17 BOLT (M10X1.5X30-MM) | 9 | |
| 6V5223 | 18 BOLT (M8X1.25X100-MM) | 2 | |
| 6V5230 | 19 BOLT (M10X1.5X60-MM) | 4 | |
| 6V5839 | 20 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V7673 | 21 BOLT (M12X1.75X50-MM) | 4 | |
| 6V9607 | 22 BOLT (M8X1.25X120-MM) | 2 | |
| 8T0643 | 23 BOLT (M10X1.5X80-MM) | 1 | |
| 4K6499 | 24 GROMMET | 1 | |
| 3000056 | 25 PLATE AS | 1 |
