System And Components
261-3041 HOUSING GP-TORQUE CONVERTERS/N KJS64-303; FRT64-303
Group No: 261-3041
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S3440 | 1 WASHER-WAVE (68.1X80.8X0.5-MM THK) | 1 | |
| 9W5531 | 2 SCREEN GP-MAGNETIC (TRANSMISSION) | 1 | |
| 1849969 | 3 GASKET | 1 | |
| 2032059 | 4 CONNECTOR AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8C6869 | CONNECTOR | 1 | |
| 2613066 | 5 STUD | 8 | |
| 2613073 | 6 COVER | 1 | |
| 2613306 | 7 STUD | 15 | |
| 2613393 | 8 STUD | 19 | |
| 2681543 | 9 ELBOW AS | 3 | |
| 2T1925 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 2767293 | 10 HOUSING AS-TORQUE CONVERTER | 1 | |
| 3L3248 | PIN | 2 | |
| 1T0477 | DOWEL | 2 | |
| 3090121 | 11 SCREEN AS (SUCTION) | 1 | |
| 3099093 | 12 HOSE AS | 1 | |
| 3099094 | 13 HOSE AS | 1 | |
| 0T0318 | 14 BOLT (7/16-14X1-IN) | 10 | |
| 1H8171 | 15 SEAL-O-RING | 1 | |
| 2613074 | 16 GASKET | 1 | |
| 2613075 | 17 COVER | 1 | |
| 2613308 | 18 COVER | 1 | |
| 2D6533 | 19 SEAL-O-RING | 1 | |
| 3E8700 | 20 SENSOR GP-TEMPERATURE (TRANSMISSION OIL) | 1 | |
| 3J1907 | 21 SEAL-O-RING | 1 | |
| 3S1546 | 22 NUT-FULL (7/16-14-THD) | 8 | |
| 5M2894 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P8211 | 24 SEAL-O-RING | 2 | |
| 5P8244 | 25 WASHER-HARD (12X22.5X2.5-MM THK) | 18 | |
| 5P9186 | 26 SEAL-O-RING | 2 | |
| 6D7146 | 27 SEAL-O-RING | 1 | |
| 6M8796 | 28 BOLT-12 POINT HEAD (3/4-10X1.75-IN) | 11 | |
| 6V2406 | 29 SEAL-O-RING | 1 | |
| 8T6761 | 30 PLUG-PIPE (1-11-1/2 NPT THD) | 3 | |
| 8T6762 | 31 PLUG-PIPE (1/2-14-THD) | 1 | |
| 9H6832 | 32 SEAL-O-RING | 1 | |
| 9S8752 | 33 NUT-FULL (3/8-16-THD) | 4 |
