382-5152 LINES GP-TURBOCHARGER WATERType 2

Group No: 382-5152

Part Number	Part Name	Qty
4P7233	1 GROMMET	7
5P8924	2 UNION	1
7N3368	3 GASKET	1
1442980	4 HOUSING	1
2340216	5 CLAMP	4
4347487	6 TUBE AS	1
4347488	7 TUBE AS	1
4690511	8 ADAPTER	1
4378491	9 BRACKET	1
4442619	10 HOSE AS	1
4494815	11 BRACKET AS	1
4494816	12 HOSE & TUBE AS	1
4566982	13 HOSE & TUBE AS	1
4590647	14 ADAPTER AS	1
2167485	SEAL-O-RING	1
2949072	SEAL-O-RING	1
4590646	ADAPTER	1
4776203	15 HOSE & TUBE AS	1
0S1590	16 BOLT (3/8-16X2-IN)	3
0S1594	17 BOLT (3/8-16X1-IN)	1
0T0573	18 BOLT (3/8-16X2.75-IN)	1
1003237	19 GROMMET	1
1336934	20 SPACER (11X20X25-MM THK)	2
1808424	21 SEAL-O-RING	13
1997854	22 SPACER (11.8X20X45-MM THK)	2
1A2029	23 BOLT (3/8-16X1.125-IN)	3
1N7284	24 BOLT-12 POINT HEAD (3/8-16X2.5-IN)	2
2167485	25 SEAL-O-RING	3
2502343	26 SEAL-O-RING	3
2877299	27 ELBOW	1
2949072	28 SEAL-O-RING	2
2B0941	29 SPACER (10.5X19X19-MM THK)	3
2T1925	30 ELBOW	1
3E2333	31 ELBOW	1
3E7403	32 ADAPTER	1
3S0127	33 BOLT-12 POINT HEAD (3/8-16X2.25-IN)	3
5M2894	34 WASHER-HARD (10.2X18.5X2.5-MM THK)	9
5P7464	35 CLIP (SLOT)	1
5P7465	36 CLIP (TAB)	1
6V1249	37 GROMMET (22-MM ID)	1
6V3251	38 SEAL-O-RING	3
6V5063	39 SEAL-O-RING	1
6V5064	40 SEAL-O-RING	2
6V6609	41 SEAL-O-RING	4
6V7543	42 BOLT-12 POINT HEAD (3/8-16X3.25-IN)	2
6V8639	43 CONNECTOR	2
2681640	44 CONNECTOR	1
6V8775	45 TEE-FACE SEAL	1
6V9004	46 ELBOW	1
6V9837	48 TEE-SWIVEL	2
6V9851	49 ELBOW	1
6V9853	50 ELBOW	1
7E7547	51 SPACER (13.9X21.3X42-MM THK)	1
8C4424	52 PLUG	2
8C6869	53 CONNECTOR	1
8C6871	54 CONNECTOR	3
8L2779	55 SEAL-O-RING	2
8T1887	56 CLIP (SLOT)	7
8T1888	57 CLIP (TAB)	7
8T7492	58 CONNECTOR	1
9S4190	59 PLUG-O-RING (7/8-14-THD)	2
9S8752	60 NUT-FULL (3/8-16-THD)	3
9X6458	61 WASHER-HARD (10.2X22.5X3-MM THK)	8
9S4185	62 PLUG (3/4-16-THD)	1
1T0720	63 BOLT-12 POINT HEAD (3/8-16X1.25-IN)	1
