System And Components
386-3182 CONTROL GP-TRANSMISSION HYDPART OF 393-7321 TRANSMISSION AR-COMPLETE
Group No: 386-3182
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4F4097 | 1 SEAL-O-RING | 1 | |
| 6D7889 | 2 SEAL-O-RING | 6 | |
| 1261773 | 3 CAP-CONNECTOR | 1 | |
| 1803178 | 4 VALVE GP-RELIEF (TORQUE CONVERTER) | 1 | |
| 1974652 | 5 VALVE-RELIEF (CLUTCH BACK PRESSURE) | 1 | |
| 2142485 | 6 SENSOR GP-SPEED (TORQUE CONVERTER) | 1 | |
| 2345013 | 7 SENSOR GP-TEMPERATURE (TRANSMISSION OIL) | 2 | |
| 2366222 | 8 SENSOR GP-SPEED (TRANSMISSION OUTPUT) | 3 | |
| 2447772 | 9 VALVE GP-MODULATING (TRANSMISSION CLUTCH, ECPC) | 6 | |
| 2764166 | 10 VALVE AS-FLOW CONTROL (FLOW DIVERTER, LUBRICATION) | 1 | |
| 2942709 | 11 HARNESS AS-SENSOR (TRANSMISSION OIL LEVEL) | 1 | |
| 3045691 | 12 CONTROL GP-UNPROGRAMMED (TRANSMISSION) | 1 | |
| 3122648 | 13 BRACKET | 1 | |
| 3710891 | 14 PLATE-SEPARATOR | 1 | |
| 3710892 | 15 GASKET | 1 | |
| 3830811 | 16 VALVE GP-RELIEF (OIL CONTROL) | 1 | |
| 3862391 | 17 HARNESS AS-TRANSMISSION | 1 | |
| 4P7581 | 18 CLIP (LADDER) | 2 | |
| 0965866 | 19 BOLT (M8X1.25X75-MM) | 4 | |
| 1305300 | 20 CLIP | 1 | |
| 1325789 | 21 CLIP (LADDER) | 5 | |
| 1499129 | 22 CLIP | 1 | |
| 1833409 | 23 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 0335853 | SEAL-O-RING | 1 | |
| 1645567 | 24 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2507194 | 25 BOLT-SPECIAL | 2 | |
| 2859066 | 26 BOLT (M8X1.25X65-MM) | 12 | |
| 9M8406 | 27 CLIP | 1 | |
| 3134613 | 28 SENSOR AS-LIQUID LEVEL (TRANSMISSION OIL) | 1 | |
| 3831393 | GROMMET | 1 | |
| 3535126 | 29 PLUG AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 3S2093 | 30 STRAP-CABLE | 11 | |
| 4P7428 | 31 CLIP | 1 | |
| 4P7429 | 32 CLIP (LADDER) | 2 | |
| 5S1522 | 33 RING-SNAP | 2 | |
| 6V5216 | 34 BOLT (M8X1.25X18-MM) | 5 | |
| 6D5801 | 35 LOCKNUT (8-32-THD) | 4 | |
| 6I1418 | 36 SPACER (8.2X12.7X28.7-MM THK) | 4 | |
| 6V0852 | 37 CAP-DUST | 7 | |
| 6V8352 | 39 SEAL-O-RING | 2 | |
| 7U4892 | 40 SCREW (8-32X0.75-IN) | 4 | |
| 8M3175 | 41 WASHER-HARD (10.2X16X3-MM THK) | 2 | |
| 8T4189 | 42 BOLT (M8X1.25X20-MM) | 3 | |
| 8T4224 | 43 WASHER-HARD (8.8X16X2-MM THK) | 24 | |
| 8T7547 | 44 BOLT (M8X1.25X30-MM) | 12 | |
| 8T6912 | 45 BOLT (M8X1.25X50-MM) | 4 | |
| 8T9655 | 47 MOUNT-ISOLATION | 8 | |
| 9N0869 | 48 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 7K1181 | 49 STRAP-CABLE | 1 | |
| 1984776 | 50 WASHER-HARD (8.8X20X8-MM THK) | 12 |
