System And Components
486-6926 CASE GP-TRANSMISSIONS/N B4R1-UP
Group No: 486-6926
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V1720 | 1 PLATE-SERIAL NUMBER (TRANSMISSION) | 1 | |
| 2582829 | 2 BREATHER (TRANSMISSION) | 1 | |
| 3533826 | 3 COVER AS-REAR | 1 | |
| 9W0718 | PLUG | 1 | |
| 3592811 | 4 GASKET | 1 | |
| 3653179 | 5 SEAL-LIP TYPE | 1 | |
| 3704648 | 6 GASKET | 1 | |
| 3720863 | 7 COVER-MANIFOLD | 1 | |
| 3810187 | 8 GASKET | 1 | |
| 3872970 | 9 GASKET | 1 | |
| 3872971 | 10 GASKET | 1 | |
| 3872973 | 11 GASKET | 1 | |
| 3872974 | 12 MANIFOLD AS | 1 | |
| 3H2617 | PIN-SPRING | 4 | |
| 3872976 | 13 HUB AS | 1 | |
| 4402301 | 14 CASE AS-TRANSMISSION | 1 | |
| 3H2617 | PIN-SPRING | 6 | |
| 4I5668 | PLUG-ORIFICE | 2 | |
| 1608742 | 15 BOLT (M10X1.5X55-MM) | 8 | |
| 1645567 | 16 COUPLER AS-QUICK DISCONNECT (MALE) | 11 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1B8074 | 17 WASHER (13.5X23.83X9.53-MM THK) | 21 | |
| 2954095 | 18 TEE AS | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2877342 | TEE | 1 | |
| 2J0157 | 19 SEAL-O-RING | 2 | |
| 3196231 | 20 PLUG AS | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 4M0189 | 21 SEAL-O-RING | 1 | |
| 6V0852 | 22 CAP-DUST | 11 | |
| 6V4249 | 23 BOLT (M10X1.5X50-MM) | 13 | |
| 6V5839 | 24 WASHER (11X21X2.5-MM THK) | 22 | |
| 7J0402 | 25 COVER | 1 | |
| 3J6933 | 26 GASKET | 1 | |
| 8T0106 | 27 BOLT (M12X1.75X100-MM) | 21 | |
| 8T0643 | 28 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4139 | 29 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 28 | |
| 8T6868 | 31 BOLT (M12X1.75X80-MM) | 24 |
