System And Components
488-3490 CAMSHAFT GPS/N TZ81-UP
Group No: 488-3490
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2487589 | 1 PIN AS-TIMING | 1 | |
| 2287105 | SEAL-O-RING | 1 | |
| 3901692 | 2 WASHER-THRUST | 1 | |
| 3908006 | 3 PLATE-THRUST | 1 | |
| 4883491 | 4 CAMSHAFT AS-FRONT | 1 | |
| 6V3535 | DOWEL | 1 | |
| 1093001 | STUD-TAPERLOCK (M10X1.5X65-MM) | 8 | |
| 4883493 | 5 CAMSHAFT-REAR | 1 | |
| 2Y5829 | 6 NUT (M10X1.5-THD) | 8 | |
| 6V5839 | 7 WASHER (11X21X2.5-MM THK) | 5 | |
| 9X8271 | 8 BOLT-12 POINT HEAD (M10X1.5X45-MM) | 5 |
