Assembly
100%

123-7876 LINES GP-HOISTS/N 2YR1-UP

Group No: 123-7876
Part NumberPart NameQty
16500251 HOSE (48IN)
4S7507SLEEVE2
4S7492STEM AS-COLLET1
4S7498STEM AS1
7U72142 TUBE AS1
12566063 TUBE AS1
12553634 HOSE AS1
7U33685 HOSE AS1
7U53066 BRACKET-MOUNTING1
1P45827 FLANGE-HALF4
1P45788 FLANGE-HALF4
1P45779 FLANGE-HALF6
5P746910 CLIP (TAB)2
5P746811 CLIP (SLOT)2
5P844412 GROMMET (37-MM ID)2
8T937713 BOLT (3/8-16X2.25-IN)4
5U813814 ADAPTER1
2P127915 LOCKNUT (9/16-18-THD)1
8T891916 BOLT (1/2-13X1.75-IN)4
8T483517 BOLT (1/2-13X2-IN)1
5P242418 BOLT (1/2-13X2.25-IN)4
8T891619 BOLT (7/16-14X1.5-IN)
5S738220 BOLT (3/8-16X1.375-IN)8
5P222821 BOLT (1/2-13X1-IN)1
6V818822 NUT (1/2-13-THD)6
5P256623 BOLT (1/2-13X1.5-IN)1
8T422324 WASHER-HARD (13.5X25.5X3-MM THK)13
8T536025 WASHER (12X22.5X2.5-MM THK)8
8T489626 WASHER-HARD (10.2X18.5X2.5-MM THK)12
6V085227 CAP-DUST1
4J052028 SEAL-O-RING4
4J052729 SEAL-O-RING2
4J052230 SEAL-O-RING2
3J190731 SEAL-O-RING1
6V864132 CONNECTOR1
3J1907SEAL-O-RING1
4J5477SEAL-O-RING1
6V862833 ELBOW2
3J7354SEAL-O-RING2
4J5477SEAL-O-RING2
6V984934 ELBOW1
4J5477SEAL-O-RING1
7X794535 ADAPTER (9/16-18-THD)1
4J5477SEAL-O-RING1
7U124838 PLATE-ADAPTER2
6V396540 FITTING (QUICK DISCONNECT)1
