220-5601 WIRING GP-CHASSISS/N JSM157-168

Group No: 220-5601
Part NumberPart NameQty
2A73211 BOX AS1
8F8551HINGE-BUTT1
2G87672 WASHER (10.5X60X3-MM THK)8
3E51693 GUARD-SWITCH1
3T30484 CLIP AS1
6B45405 NUT (4-40-THD)4
6D30336 SCREW-SOCKET HEAD (4-40X0.5-IN)4
6G22567 CLAMP4
6V94978 WASHER-HARD (3.2X6X0.5-MM THK)4
6W76369 SPACER (11.13X19.05X30-MM THK)6
8D953710 CAP-DUST1
8X808211 BRACKET2
9G710112 SPACER (11X20X30-MM THK)5
9G915013 CLIP1
9X026114 ADAPTER2
9X349515 CLIP AS1
9X685516 SWITCH AS-PRESSURE (BRAKE OIL ACCUMULATOR)1
5P6008TUBE-HEAT SHRINK (6.35-MM DIA)(.2M)
8T5677SLEEVE (.6M)
7N7779SOCKET-CONNECTOR (14-GA TO 18-GA)1
7N7780PIN-CONNECTOR (14-GA TO 18-GA)2
7N7781HOUSING-RECEPTACLE (14-GA TO 18-GA)1
102140017 SENSOR GP-PRESSURE (AUTOMATIC LUBRICATION)1
106870418 SUPPRESSOR AS-ARC2
107228219 LAMP GP-SIGNAL (24-VOLT)(BLUE)1
116011820 CLIP2
117777321 SWITCH AS-PRESSURE (DIFFERENTIAL)2
1028802KIT-RECEPTACLE (2-PIN)1
3E3365WEDGE-RECEPTACLE LOCK (2-PIN)1
1863735PIN-CONNECTOR (16-GA TO 18-GA)1
9X1813SLEEVE (14CM)
117907922 PLATE AS1
118042923 PLATE AS1
134225224 SENSOR GP-TEMPERATURE (8-VOLT)(LH & RH FRT & RR BK)2
118722624A SENSOR GP-TEMPERATURE (STEERING TANK)1
123644925 ALARM GP1
126018226 BUFFER GP-SENSOR (FUEL LEVEL)1
135042627 LAMP GP-SIGNAL (24-VOLT, STOP, TAIL)(STOP/TAIL)2
135042728 LAMP GP-SIGNAL (24-VOLT, PARK, TURN)(TURN/PARK)2
138750029 SPACER (11X25X50-MM THK)1
139211630 SWITCH GP-TOGGLE (ACCESS LIGHTS)1
3E3371WEDGE-RECEPTACLE LOCK (3-PIN)1
6T3631NUT-HEX (15/32-32-THD)2
6T3632LOCKWASHER1
6T3633RING-LOCKING1
1863735PIN-CONNECTOR (16-GA TO 18-GA)1
1028802KIT-RECEPTACLE (2-PIN)1
139211831 SWITCH AS-TOGGLE (ENGINE SERVICE LIGHTS)1
3E3365WEDGE-RECEPTACLE LOCK (2-PIN)1
6T3631NUT-HEX (15/32-32-THD)2
6T3632LOCKWASHER1
6T3633RING-LOCKING1
1863735PIN-CONNECTOR (16-GA TO 18-GA)1
1028802KIT-RECEPTACLE (2-PIN)1
143917032 SENSOR GP-PRESSURE (LH & RH PARKING BRAKE RELEASE)2
156956333 HARNESS AS-CHASSIS (CAB TO ENGINE)(CAB TO ENGINE)1
158048734 ROD1
5C7261NUT (M8X1.25-THD)1
7X7915ROD END1
8T4133NUT (M10X1.5-THD)1
8T6431ROD END1
158048935 CHANNEL AS1
8T3490NUT-WELD (M10X1.5-THD)2
1019080BOSS (M10X1.5X13-MM)7
159542636 CABLE AS1
1S7251TERMINAL-CABLE (00-GA, 1/2-IN SCREW)1
8N0869COVER-TERMINAL (RED)2
0301706TERMINAL-RING (00-GA, 1/4-IN SCREW)1
1598049CABLE (00-GA, RED)(900CM)
159542737 CABLE AS1
1S7251TERMINAL-CABLE (00-GA, 1/2-IN SCREW)1
5P0747CABLE (00-GA, BLACK)(80CM)
8S3020TERMINAL-CABLE (00-GA, 3/8-IN SCREW)1
0375197BOOT1
153207338 LAMP GP-FLOOD (24-VOLT)(ENGINE WORK)2
168039139 PLATE2
170251240 SWITCH GP-TOGGLE (ENGINE SHUTDOWN)1
3E3383WEDGE-RECEPTACLE LOCK (6-PIN)1
6T3631NUT-HEX (15/32-32-THD)2
6T3632LOCKWASHER1
6T3633RING-LOCKING1
1863735PIN-CONNECTOR (16-GA TO 18-GA)1
1028805KIT-RECEPTACLE (6-PIN)1
173267941 SWITCH AS-PRESSURE (STEERING)(HIGH)1
185620742 CABLE AS1
5P0747CABLE (00-GA, BLACK)(720CM)
7N5274COVER AS-TERMINAL (BLACK)1
8L8413STRAP-CABLE (WHITE)1
8S3020TERMINAL-CABLE (00-GA, 3/8-IN SCREW)1
3S6050TERMINAL AS-BATTERY (NEGATIVE)1
1M6119BOLT (5/16-18X1.375-IN)1
1M6120NUT (5/16-18-THD)1
192895843 BRACKET AS2
8T3490NUT-WELD (M10X1.5-THD)2
192895944 BRACKET AS3
8T3490NUT-WELD (M10X1.5-THD)2
192896045 BRACKET2
192896146 BRACKET3
193466547 HARNESS AS (BUMPER TO RIGHT SIDE)1
1028803KIT-RECEPTACLE (3-PIN)2
1552255KIT-CONNECTING PLUG (12-PIN)1
1552260KIT-CONNECTING PLUG (3-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)3
193466648 HARNESS AS (797 BUMPER)1
1028801KIT-RECEPTACLE (12-PIN)1
1028802KIT-RECEPTACLE (2-PIN)1
1552255KIT-CONNECTING PLUG (12-PIN)
1552260KIT-CONNECTING PLUG (3-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)6
1552274KIT-CONNECTING PLUG (6-PIN)2
198427149 LEVER1
198837250 SENSOR GP-POSITION (ROTARY)(TRUCK BODY)1
209213051 SENSOR GP-PRESSURE (STEERING ACCUMULATOR)1
209361352 HARNESS AS (CAB TO TAIL CASTING)1
209361453 HARNESS AS (797 REAR)1
1552260KIT-CONNECTING PLUG (3-PIN)7
1552270KIT-CONNECTING PLUG (2-PIN)6
219306754 HARNESS AS-CHASSIS (CAB TO TRANSMISSION INPUTS)1
219306855 HARNESS AS-CHASSIS (CAB TO TRANSMISSION OUTPUTS)1
220561556 HARNESS AS (CAB TO BUMPER)1
1028802KIT-RECEPTACLE (2-PIN)3
1028803KIT-RECEPTACLE (3-PIN)1
1552260KIT-CONNECTING PLUG (3-PIN)1
1552255KIT-CONNECTING PLUG (12-PIN)1
1552265KIT-CONNECTING PLUG (8-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)6
220561757 HARNESS AS (CAB TO LEFT MIDDLE)1
1028803KIT-RECEPTACLE (3-PIN)2
1552260KIT-CONNECTING PLUG (3-PIN)2
1552270KIT-CONNECTING PLUG (2-PIN)9
1552271KIT-CONNECTING PLUG (4-PIN)1
221044758 BRACKET AS1
221044959 BRACKET1
230730360 HARNESS AS (MIDDLE TO RIGHT SIDE)1
1028803KIT-RECEPTACLE (3-PIN)1
1552260KIT-CONNECTING PLUG (3-PIN)1
033824861 CLIP (LOOP)11
091008162 SPACER (10.5X20X10-MM THK)15
105348763 BOLT-SOCKET HEAD (M6X1X20-MM)1
130530064 CLIP24
130530165 CLIP2
161350966 LAMP GP-HEAD (24-VOLT)(LOW BEAM)(FOG)4
161090867 LAMP GP-HEAD (24-VOLT)(LOW BEAM)(REAR BACKUP)2
186604768 SENDER AS (STEERING TANK)1
1J967169 SEAL-O-RING1
1S099470 CLIP (LOOP)16
1S099671 CLIP1
1S642072 CLIP2
205307973 ADAPTER1
223825174 HARNESS AS-SWITCH (BRAKE)(RR PARK BK REL PRESS ARC SUPPR)2
1028803KIT-RECEPTACLE (3-PIN)1
1552260KIT-CONNECTING PLUG (3-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)1
2T301975 CLIP (LOOP)5
3J190776 SEAL-O-RING8
3J735477 SEAL-O-RING3
3S866478 CLIP6
3S866579 CLIP (LOOP)6
4D779480 CLIP14
4K830281 CLIP (LOOP)1
4K886482 CLIP (LOOP)4
4P758183 CLIP (LADDER)10
4P758284 CLIP (LADDER)2
4P813485 CLIP (LADDER)3
4S196286 CLIP (LOOP)1
4S445587 CLIP6
5C289088 NUT (M6X1-THD)15
5C726189 NUT (M8X1.25-THD)1
5C831290 NUT (M4X0.7-THD)28
5P747091 CLIP (SLOT)2
5P747192 CLIP (TAB)2
5P770393 GROMMET (52-MM ID)2
5P785494 CLIP (LOOP)10
5P929795 CLIP (LOOP)6
5P929996 CLIP (LOOP)1
5P961797 ADAPTER1
6D424498 CLIP (LOOP)14
6K817899 CLIP (LOOP)1
6V1889100 CLIP (LOOP)24
6V4298101 BOLT (M5X0.8X16-MM)5
6V5230102 BOLT (M10X1.5X60-MM)2
6V5843103 BOLT (M10X1.5X45-MM)1
6V8212104 BOLT (M10X1.5X16-MM)1
7K1181105 STRAP-CABLE67
7N0718106 SWITCH GP-DISCONNECT1
7N3718107 CLIP1
7X2621109 BOLT (M10X1.5X12-MM)7
7X7729110 WASHER (11X25X3-MM THK)3
8C9660111 WASHER (4.6X7.9X0.8-MM THK)56
8K1433112 GROMMET1
8M2770113 CLIP (LOOP)17
8M2773114 CLIP (LOOP)9
8S7583115 GROMMET1
8T0328116 WASHER-HARD (5.5X10X1-MM THK)5
8T0338117 BOLT-SOCKET HEAD (M8X1.25X45-MM)5
8T4121118 WASHER-HARD (11X21X2.5-MM THK)208
8T4133119 NUT (M10X1.5-THD)20
8T4136120 BOLT (M10X1.5X25-MM)10
8T4137121 BOLT (M10X1.5X20-MM)146
8T4139122 BOLT (M12X1.75X30-MM)4
8T4179123 BOLT (M12X1.75X20-MM)5
8T4185124 BOLT (M10X1.5X50-MM)7
8T4192125 BOLT (M12X1.75X25-MM)2
8T4195126 BOLT (M10X1.5X30-MM)23
8T4205127 WASHER-HARD (7.2X14.5X2-MM THK)15
8T4223128 WASHER-HARD (13.5X25.5X3-MM THK)11
8T4896129 WASHER-HARD (10.2X18.5X2.5-MM THK)2
8T5005130 BOLT (M10X1.5X70-MM)1
8T6466131 BOLT (M10X1.5X60-MM)6
8T7547132 BOLT (M8X1.25X30-MM)1
8T9379133 BOLT (3/8-16X4.25-IN)2
8T9405134 BOLT-SOCKET HEAD (M4X0.7X16-MM)28
8X5740135 CABLE AS1
0350425RING-TERMINAL (000-GA, 3/8-IN SCREW)1
9G8909COVER-TERMINAL (BLACK)2
5P2600RING-TERMINAL (000-GA, 1/2-IN SCREW)1
5P0744CABLE (00-GA, BLACK)(93CM)
9D3768136 GROMMET1
9G7641137 SWITCH GP-START (ENGINE, KEY)1
9M1974138 WASHER-HARD (8.8X16X2-MM THK)7
9M8406139 CLIP (LOOP)34
9R7240140 GASKET1
