System And Components
272-3290 LINES GP-POWER TRAIN OILS/N LAJ1-182
Group No: 272-3290
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W2033 | 1 CLIP (TAB) | 1 | |
| 8X9882 | 2 PLATE | 1 | |
| 1053378 | 3 ELBOW | 1 | |
| 1362617 | 4 HOSE AS | 1 | |
| 1598945 | 5 HOSE AS | 1 | |
| 1749708 | 6 ADAPTER-FILTER | 1 | |
| 2199654 | 7 CONNECTOR AS | 1 | |
| 1093657 | CONNECTOR | 1 | |
| 6K6307 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 2746412 | 8 HOSE AS | 1 | |
| 2871501 | 9 SCREEN | 1 | |
| 2906450 | 10 HOSE AS | 2 | |
| 2910100 | 11 HOSE AS | 1 | |
| 2922195 | 12 ELBOW | 1 | |
| 3001694 | 13 HOSE AS | 1 | |
| 3172423 | 14 BRACKET AS | 1 | |
| 3219619 | 15 HOSE AS | 1 | |
| 3381016 | 16 HOSE AS | 1 | |
| 3381017 | 17 HOSE AS | 1 | |
| 1223606 | 18 CLIP (LOOP) | 1 | |
| 1333260 | 19 SPACER (11X19X10-MM THK) | 1 | |
| 1488336 | 20 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488340 | 21 CONNECTOR AS | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488355 | 22 ELBOW AS | 1 | |
| 6V9005 | ELBOW | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488364 | 23 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488406 | 24 PLUG AS | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488435 | 25 TEE AS | 4 | |
| 6V8781 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1503028 | 26 ELBOW AS | 1 | |
| 6V9343 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1553624 | 27 PLUG AS | 1 | |
| 9S4182 | PLUG (7/16-20-THD) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1645590 | 28 VALVE AS-FLUID SAMPLING | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1695862 | 29 ELBOW AS | 1 | |
| 8C6712 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1716720 | 30 ELBOW AS | 1 | |
| 1023437 | ELBOW | 1 | |
| 8T0315 | SEAL-O-RING | 1 | |
| 1741530 | 31 PLUG AS | 1 | |
| 1N5998 | PLUG | 1 | |
| 6K6307 | SEAL-O-RING | 1 | |
| 1P4582 | 32 FLANGE-HALF | 2 | |
| 1P4585 | 33 FLANGE-HALF | 8 | |
| 2H6338 | 34 SEAL-O-RING | 4 | |
| 4J0527 | 35 SEAL-O-RING | 1 | |
| 4L9564 | 36 SEAL-O-RING | 1 | |
| 4T6788 | 37 FILTER-OIL (ADVANCED EFFICIENCY) | 1 | |
| 5P1076 | 38 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 5P7462 | 39 CLIP (SLOT) | 1 | |
| 5P7463 | 40 CLIP (TAB) | 1 | |
| 5P7464 | 41 CLIP (SLOT) | 1 | |
| 5P7465 | 42 CLIP (TAB) | 1 | |
| 6F8146 | 43 SEAL-O-RING | 1 | |
| 6V0683 | 44 GROMMET | 1 | |
| 6V1249 | 45 GROMMET (22-MM ID) | 1 | |
| 5P7703 | 46 GROMMET (52-MM ID) | 1 | |
| 7M8485 | 47 SEAL-O-RING | 1 | |
| 7W2034 | 48 CLIP (SLOT) | 1 | |
| 7X2558 | 49 BOLT (M16X2X150-MM) | 4 | |
| 8C3447 | 50 CAP-DUST | 1 | |
| 8C8533 | 51 CLIP | 1 | |
| 8T4121 | 52 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 53 NUT (M10X1.5-THD) | 1 | |
| 8T4140 | 54 BOLT (M16X2X60-MM) | 8 | |
| 8T4176 | 55 BOLT (M12X1.75X90-MM) | 4 | |
| 8T4183 | 56 BOLT (M12X1.75X40-MM) | 5 | |
| 8T4192 | 57 BOLT (M12X1.75X25-MM) | 8 | |
| 8T4193 | 58 BOLT (M16X2X50-MM) | 8 | |
| 8T4194 | 59 BOLT (M12X1.75X50-MM) | 1 | |
| 8T4196 | 60 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4223 | 61 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 8T4244 | 62 NUT (M12X1.75-THD) | 3 | |
| 8T4956 | 63 BOLT (M12X1.75X35-MM) | 1 | |
| 9X8257 | 64 WASHER (17.5X30X3.5-MM THK) | 20 | |
| 5P7470 | 65 CLIP (SLOT) | 1 | |
| 5P7471 | 66 CLIP (TAB) | 1 |
