System And Components
457-6662 LINES GP-TORQUE CONV COOLERS/N DLW1-UP
Group No: 457-6662
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P4889 | 1 SEAL-O-RING | 1 | |
| 6V0852 | 2 CAP-DUST | 2 | |
| 7V8532 | 3 SPACER | 1 | |
| 9G5127 | 4 BREATHER (ATMOSPHERIC AIR)(TORQUE CONVERTER) | 1 | |
| 0336031 | 5 SEAL-O-RING | 3 | |
| 1260814 | 6 FITTING AS (SWIVEL) | 1 | |
| 6V0852 | CAP-DUST | 1 | |
| 1481928 | 7 VALVE-RELIEF | 1 | |
| 1488440 | 8 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8C0569 | TEE-O-RING | 1 | |
| 2083019 | 9 VALVE GP-RELIEF (TORQUE CONVERTER OUTLET) | 1 | |
| 2858028 | 10 TUBE AS | 1 | |
| 2858029 | 11 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 3685063 | 12 TUBE AS | 1 | |
| 8M7160 | MAGNET | 3 | |
| 4338205 | 13 MANIFOLD | 1 | |
| 4349572 | 14 HOSE AS | 1 | |
| 4349579 | 15 HOSE AS | 1 | |
| 4349640 | 16 HOSE AS | 1 | |
| 4370896 | 17 COVER | 1 | |
| 4604366 | 18 MANIFOLD | 1 | |
| 4631816 | 19 TUBE AS | 1 | |
| 4769715 | 20 HOSE AS | 1 | |
| 4780229 | 21 HOSE AS | 1 | |
| 4796138 | 22 HOSE AS | 1 | |
| 3308197 | 23 SEAL-O-RING | 1 | |
| 1361122 | 24 SPACER (13.8X25X10-MM THK) | 1 | |
| 1488316 | 25 CONNECTOR AS | 2 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1488339 | 26 CONNECTOR AS | 1 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488356 | 27 ELBOW AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 6V9009 | ELBOW | 1 | |
| 1488364 | 28 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488371 | 29 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8C8988 | ELBOW | 1 | |
| 1488374 | 30 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 1488378 | 31 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1645567 | 32 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1P3705 | 33 SEAL-RECTANGULAR | 3 | |
| 1P4577 | 34 FLANGE-HALF | 6 | |
| 1P4578 | 35 FLANGE-HALF | 4 | |
| 1P4579 | 36 FLANGE-HALF | 8 | |
| 1P4584 | 37 FLANGE-HALF | 2 | |
| 1S0996 | 38 CLIP | 1 | |
| 1S6420 | 39 CLIP | 1 | |
| 3260315 | 40 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P3501 | ADAPTER | 1 | |
| 3390078 | 41 ADAPTER | 1 | |
| 3K0360 | 42 SEAL-O-RING | 1 | |
| 3T6471 | 43 SCREEN AS (TORQUE CONVERTER) | 1 | |
| 3T6469 | WASHER (19X26X1.6-MM THK) | 1 | |
| 4349577 | 44 HOSE AS | 1 | |
| 4769494 | 45 HOSE AS | 1 | |
| 4J0520 | 46 SEAL-O-RING | 5 | |
| 4J0522 | 47 SEAL-O-RING | 4 | |
| 4J0524 | 48 SEAL-O-RING | 4 | |
| 5558483 | 49 FLANGE | 1 | |
| 5655081 | 50 HOSE AS | 1 | |
| 5664774 | 51 MANIFOLD | 1 | |
| 5816869 | 52 HOSE AS | 1 | |
| 3308196 | 53 SEAL-O-RING | 1 | |
| 7S8920 | 54 CLIP (SLOT) | 2 | |
| 7S8921 | 55 CLIP (TAB) | 2 | |
| 7X2549 | 56 BOLT (M12X1.75X100-MM) | 1 | |
| 7X7960 | 57 BOLT (M12X1.75X220-MM) | 4 | |
| 8C3206 | 58 FLANGE-HALF | 4 | |
| 8J4351 | 59 SEAL-O-RING | 1 | |
| 8T4121 | 60 WASHER-HARD (11X21X2.5-MM THK) | 38 | |
| 8T4139 | 61 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4178 | 62 BOLT (M10X1.5X90-MM) | 7 | |
| 8T4183 | 63 BOLT (M12X1.75X40-MM) | 6 | |
| 8T4184 | 64 BOLT (M12X1.75X45-MM) | 14 | |
| 8T4186 | 65 BOLT (M10X1.5X40-MM) | 4 | |
| 1837121 | 66 BOLT (M10X1.5X35-MM) | 24 | |
| 8T4223 | 67 WASHER-HARD (13.5X25.5X3-MM THK) | 42 | |
| 8T4956 | 68 BOLT (M12X1.75X35-MM) | 1 | |
| 8T5005 | 69 BOLT (M10X1.5X70-MM) | 3 | |
| 8T6868 | 70 BOLT (M12X1.75X80-MM) | 6 | |
| 8T8920 | 71 BOLT (1/2-13X3.25-IN) | 8 | |
| 8T9527 | 72 SEAL-O-RING | 1 | |
| 9P0214 | 73 SCREEN AS (POWER TRAIN OIL) | 1 |
