Assembly
100%

121-6697 MOUNTING GP-CABS/N 7NN1-176

Group No: 121-6697
Part NumberPart NameQty
1G39511 PLATE AS (RH)1
1G39522 PLATE AS (LH)1
1G39533 TAP2
1G39544 SPACER2
1G38615 MOUNT-FLEXIBLE2
1G39486 PLATE2
1G38667 MOUNT-FLEXIBLE2
3E98648 LOCKNUT (1-8-THD)4
5C95539 BOLT (M6X1X16-MM)2
5E650410 SHIM2
5P411611 WASHER-HARD (8.8X20.5X2-MM THK)5
6V768712 LOCKNUT (M12X1.75-THD)4
6V768813 LOCKNUT (M20X2.5-THD)2
6V774414 LOCKNUT (M10X1.5-THD)4
6V818215 NUT (3/4-10-THD)4
7X037016 BOLT (3/4-10X3.5-IN)8
7X041217 BOLT (1-8X4.75-IN)2
7X041818 BOLT (1-8X9.5-IN)2
8T412119 WASHER-HARD (11X21X2.5-MM THK)10
8T413320 NUT (M10X1.5-THD)2
8T413921 BOLT (M12X1.75X30-MM)2
8T417622 BOLT (M12X1.75X90-MM)2
8T418323 BOLT (M12X1.75X40-MM)2
8T418924 BOLT (M8X1.25X20-MM)5
8T419626 BOLT (M10X1.5X35-MM)2
8T422327 WASHER-HARD (13.5X25.5X3-MM THK)8
8T424428 NUT (M12X1.75-THD)4
8T499429 WASHER-HARD (20X36.5X3.5-MM THK)12
7X256430 BOLT (M20X2.5X90-MM)2
9X825631 WASHER (6.6X12X2-MM THK)2
9X849932 BOLT (M12X1.75X60-MM)2
081409733 WASHER2
110942534 DOOR AS1
123074535 COVER1
112664636 LOCKNUT (M6X1-THD)2
101284237 FILM-INSTRUCTION (ALTERNATE EXIT)1
