System And Components
370-0100 CANOPY GPS/N MAT1-UP
Group No: 370-0100
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5E9892 | 1 PIN | 1 | |
| 5P7958 | 2 SLEEVE-CABLE SPLICE | 2 | |
| 1846893 | 3 ELBOW | 1 | |
| 0398869 | 4 TUBE | 4 | |
| 0813772 | 5 LEVER | 1 | |
| 1149284 | 6 BUMPER | 2 | |
| 1284119 | 7 CYLINDER AS-TILT | 1 | |
| 1284120 | 8 PUMP AS-HAND (TILT CYLINDER) | 1 | |
| 2817715 | FILM-INSTRUCTION (CAB LIFT) | 1 | |
| 1355049 | 9 CABLE AS | 1 | |
| 1671192 | 10 CLIP | 2 | |
| 2240554 | 11 FILM-WARNING (UNIVERSAL, READ OMM) | 1 | |
| 2387609 | 12 PIN | 2 | |
| 2586607 | 13 SPACER (8.4X14X17-MM THK) | 4 | |
| 2803991 | 14 STUD-BALL | 2 | |
| 2803992 | 15 CLIP-RETAINING | 2 | |
| 3033427 | 16 FILM-IDENTIFICATION (CAT) | 1 | |
| 3320114 | 17 SPRING-GAS | 1 | |
| 3596089 | 18 SUPPORT AS-REAR | 2 | |
| 3596090 | 19 ARM AS-PIVOT | 1 | |
| 3596091 | 20 SUPPORT AS-FRONT (RH) | 1 | |
| 3596092 | 21 SUPPORT AS-FRONT (LH) | 1 | |
| 3596093 | 22 CANOPY GP (TOP) | 1 | |
| 3617376 | 23 WALKWAY AS (LH) | 1 | |
| 3617377 | 24 WALKWAY AS (RH) | 1 | |
| 3626076 | 25 PAD | 2 | |
| 3628121 | 26 HOSE AS | 2 | |
| 3638786 | 27 PIN-CLEVIS | 2 | |
| 3682348 | 28 PIN-LOCK | 2 | |
| 3717652 | 29 SHIELD | 1 | |
| 3721282 | 30 STACK GP-PAVER VENTILATION | 1 | |
| 3790101 | 31 ARM AS | 1 | |
| 5P7957 | 32 LANYARD | 2 | |
| 1488320 | 33 CONNECTOR AS | 3 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C6865 | CONNECTOR | 1 | |
| 1542302 | 34 SPACER (11X20X15-MM THK) | 4 | |
| 1733651 | 35 PIN-CLEVIS | 7 | |
| 3B4617 | 36 PIN-COTTER | 2 | |
| 3B4629 | 37 PIN-COTTER | 9 | |
| 4J5477 | 38 SEAL-O-RING | 1 | |
| 5C2874 | 39 NUT (M5X0.8-THD) | 2 | |
| 5C2890 | 40 NUT (M6X1-THD) | 2 | |
| 5C7261 | 41 NUT (M8X1.25-THD) | 6 | |
| 5P1076 | 42 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 5P4116 | 43 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 7I2273 | 44 BOLT (M5X0.8X16-MM) | 2 | |
| 7X2537 | 45 BOLT (M8X1.25X35-MM) | 4 | |
| 7X7729 | 46 WASHER (11X25X3-MM THK) | 4 | |
| 8T0328 | 47 WASHER-HARD (5.5X10X1-MM THK) | 4 | |
| 8T4121 | 48 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4137 | 49 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4138 | 50 BOLT (M6X1X20-MM) | 2 | |
| 8T4183 | 51 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4194 | 52 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4195 | 53 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4222 | 54 WASHER-PLATED (11X32X2.5-MM THK) | 8 | |
| 8T4224 | 55 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 8T4244 | 56 NUT (M12X1.75-THD) | 4 | |
| 8T4908 | 57 BOLT (M8X1.25X25-MM) | 4 | |
| 8T4956 | 58 BOLT (M12X1.75X35-MM) | 4 | |
| 8T6870 | 59 BOLT (M8X1.25X70-MM) | 4 | |
| 8T7547 | 60 BOLT (M8X1.25X30-MM) | 4 | |
| 8T7934 | 61 WASHER-HARD (11X21X5-MM THK) | 3 | |
| 9X8256 | 62 WASHER (6.6X12X2-MM THK) | 4 |
