System And Components
307-9804 CYLINDER & MTG GP-TILTS/N C5P1-UP; C5S1-UP
Group No: 307-9804
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1846893 | 1 ELBOW | 1 | |
| 7X0564 | 2 WASHER-HARD (20X51X3-MM THK) | 2 | |
| 0813119 | 3 SEAL-RUBBER | 2 | |
| 0813772 | 4 LEVER | 1 | |
| 1072207 | 5 RIVET-POP | 2 | |
| 1281624 | 6 SUPPORT AS | 1 | |
| 1284119 | 7 CYLINDER AS-TILT | 1 | |
| 1284120 | 8 PUMP AS-HAND (TILT CYLINDER) | 1 | |
| 2817715 | FILM-INSTRUCTION (CAB LIFT) | 1 | |
| 1477370 | 9 BRACKET AS | 1 | |
| 3732353 | 10 HOSE AS | 2 | |
| 1671192 | 11 CLIP | 2 | |
| 1488320 | 12 CONNECTOR AS | 3 | |
| 8C6865 | CONNECTOR | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 3E9862 | 13 LOCKNUT (3/4-10-THD) | 2 | |
| 4J5477 | 14 SEAL-O-RING | 1 | |
| 7X0370 | 15 BOLT (3/4-10X3.5-IN) | 1 | |
| 7X7729 | 16 WASHER (11X25X3-MM THK) | 2 | |
| 8C6857 | 17 BOLT (3/4-10X2.75-IN) | 1 | |
| 8T4136 | 18 BOLT (M10X1.5X25-MM) | 2 | |
| 7X2553 | 19 BOLT (M16X2X40-MM) | 4 | |
| 9X8257 | 20 WASHER (17.5X30X3.5-MM THK) | 4 |
