System And Components
490-6823 LINES GP-CENTRAL LUBRICATIONS/N KT41-UP
Group No: 490-6823
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF) | 16 | |
| 7K1181 | 2 STRAP-CABLE | 16 | |
| 8X3163 | 3 BLOCK | 1 | |
| 1243019 | 4 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1262565 | 5 ADAPTER | 2 | |
| 1939131 | 6 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2287080 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4906828 | 8 HOSE AS | 1 | |
| 4906831 | 9 HOSE AS | 1 | |
| 4938560 | 10 HOSE AS | 1 | |
| 4938569 | 11 HOSE AS | 1 | |
| 4938570 | 12 PLATE | 1 | |
| 5010643 | 13 HOSE AS | 1 | |
| 5102795 | 14 HOSE AS | 1 | |
| 5102796 | 15 HOSE AS | 1 | |
| 5174994 | 16 HOSE AS | 1 | |
| 5174995 | 17 HOSE AS | 1 | |
| 1240174 | 18 CLIP (LOOP) | 13 | |
| 1336934 | 19 SPACER (11X20X25-MM THK) | 6 | |
| 1488316 | 20 CONNECTOR AS | 2 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1488320 | 21 CONNECTOR AS | 4 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C6865 | CONNECTOR | 1 | |
| 1488351 | 22 ELBOW AS | 6 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V9849 | ELBOW | 1 | |
| 1488369 | 23 ELBOW AS | 6 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8628 | ELBOW | 1 | |
| 1488389 | 24 ELBOW AS | 2 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7X0492 | ELBOW | 1 | |
| 1553624 | 25 PLUG AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 9S4182 | PLUG (7/16-20-THD) | 1 | |
| 1846893 | 26 ELBOW | 3 | |
| 2P1279 | 27 LOCKNUT (9/16-18-THD) | 1 | |
| 3048044 | 28 ADAPTER AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 3048043 | ADAPTER-BULKHEAD | 1 | |
| 3445675 | 29 NUT (M10X1.5-THD) | 4 | |
| 4J5477 | 30 SEAL-O-RING | 3 | |
| 5M6214 | 31 PLUG (1/8-27 PTF) | 1 | |
| 6K5967 | 32 CLIP | 9 | |
| 6K6967 | 33 ADAPTER-PIPE | 3 | |
| 7X7729 | 34 WASHER (11X25X3-MM THK) | 5 | |
| 8T4121 | 35 WASHER-HARD (11X21X2.5-MM THK) | 26 | |
| 8T4137 | 36 BOLT (M10X1.5X20-MM) | 17 | |
| 8T4139 | 37 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4185 | 38 BOLT (M10X1.5X50-MM) | 6 | |
| 8T4223 | 39 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T5005 | 40 BOLT (M10X1.5X70-MM) | 4 | |
| 8X4856 | 41 BLOCK | 1 | |
| 1602242 | 42 SLEEVE-ABRASION (41.4-IN) | ||
| 1602242 | 42A SLEEVE-ABRASION (21-IN) | ||
| 1602242 | 42B SLEEVE-ABRASION (15.7-IN) | ||
| 1602242 | 42C SLEEVE-ABRASION (17.72-IN) | ||
| 1602242 | 42D SLEEVE-ABRASION (22.9-IN) | ||
| 1602242 | 42E SLEEVE-ABRASION (18.1-IN) | ||
| 1602242 | 42F SLEEVE-ABRASION (26.8-IN) |
