System And Components
510-7272 MOUNTING GP-SENSORPART OF 511-0223, 511-8952 KIT-OBJECT DETECTION
Group No: 510-7272
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3269055 | 1 FILM-INSTRUCTION (NO STEP) | 2 | |
| 3494915 | 2 BRACKET | 4 | |
| 3605282 | 3 PLATE AS | 2 | |
| 9R3845 | BOSS (M12X1.75X38-MM) | 4 | |
| 3729143 | 4 PLATE | 2 | |
| 3786997 | 5 BRACKET AS | 2 | |
| 3787007 | 6 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3798128 | 7 MOUNTING GP-SENSOR (RADAR) | 1 | |
| 3804489 | 8 PLATE | 8 | |
| 3806932 | 9 BRACKET | 6 | |
| 4582204 | 10 BRACKET AS | 4 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 4582206 | 11 BRACKET AS | 2 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 4582205 | BRACKET | 1 | |
| 4625005 | 12 BOX GP-OBJECT DETECTION (RADAR) | 8 | |
| 1984778 | 13 WASHER-HARD (13.5X30X12-MM THK) | 12 | |
| 2659596 | 14 WASHER-HARD (13.5X30X9-MM THK) | 32 | |
| 5C9553 | 15 BOLT (M6X1X16-MM) | 12 | |
| 5P4116 | 16 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 6V7744 | 17 LOCKNUT (M10X1.5-THD) | 24 | |
| 7X7729 | 18 WASHER (11X25X3-MM THK) | 76 | |
| 8T4183 | 19 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4186 | 20 BOLT (M10X1.5X40-MM) | 24 | |
| 8T4189 | 21 BOLT (M8X1.25X20-MM) | 8 | |
| 8T4194 | 22 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4195 | 23 BOLT (M10X1.5X30-MM) | 44 | |
| 9X8256 | 24 WASHER (6.6X12X2-MM THK) | 12 |
