272-3279 WIRING GP-SENSOR -RADIATOR COOLINGS/N WSP130-UP

Group No: 272-3279
Part NumberPart NameQty
7K11811 STRAP-CABLE1
11140122 GROMMET1
13611223 SPACER (13.8X25X10-MM THK)2
16087084 BRACKET AS2
16302355 SEAL1
18601316 SENSOR GP-SPEED (FAN SPEED)1
42653807 LAMP GP-FLOOD (9/32-VOLT)1
24358218 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
28306579 CABLE AS (VIDEO, 3-M)1
336668710 CAP-PROTECTIVE (FEMALE)1
336669211 CAP-PROTECTIVE (MALE)1
430944912 SENSOR GP-COOLANT LEVEL (JACKET WATER)1
485959513 HARNESS AS-FRONT1
033824814 CLIP (LOOP)1
091903515 SPACER (11X25X20-MM THK)1
130530016 CLIP3
133693417 SPACER (11X20X25-MM THK)1
198477718 WASHER-HARD (11X25X10-MM THK)1
204228119 STRAP-CABLE46
204800020 MOUNTING-CABLE TIE40
230773221 MOUNTING-CABLE TIE2
231033622 STUD-TAPERLOCK (M10X1.5X70-MM)2
2D129023 GROMMET1
302655024 SPACER (11X16X40-MM THK)(ATMOSPHERIC)1
305066025 SPACER (10.5X15X15-MM THK)1
344567526 NUT (M10X1.5-THD)2
345375327 MOUNTING-CABLE TIE2
352420028 STRAP-CABLE2
4P758129 CLIP (LADDER)1
5P908531 CLIP (LOOP)2
5P929732 CLIP (LOOP)3
6V822733 NUT (M18X1.5-THD)1
7X772934 WASHER (11X25X3-MM THK)1
8T412135 WASHER-HARD (11X21X2.5-MM THK)32
8T413636 BOLT (M10X1.5X25-MM)13
8T413737 BOLT (M10X1.5X20-MM)9
8T418538 BOLT (M10X1.5X50-MM)2
8T418639 BOLT (M10X1.5X40-MM)1
8T419140 BOLT (M10X1.5X16-MM)1
8T419541 BOLT (M10X1.5X30-MM)2
8T419642 BOLT (M10X1.5X35-MM)2
8T646643 BOLT (M10X1.5X60-MM)1
8T947144 GROMMET1
7X787745 STRIP-EDGE (26-CM)
7X787745A STRIP-EDGE (21-CM)
5P602946 LOCKWIRE (1-DM)
481979947 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)5
180921448 NUT (1-11/16-18-THD)1
128424949 LOCKWASHER1
