System And Components
243-1843 WIRING GP-SCREED -ELECTRIC HEATFOR USE WITH AP-800D,BG-230D
Group No: 243-1843
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X9918 | 1 GRIP-HANDLE | 2 | |
| 1961297 | 2 PANEL GP-ELECTRONIC (LH)(LH) | 1 | |
| 1961297 | 2A PANEL GP-ELECTRONIC (LH)(RH) | 1 | |
| 2316635 | 3 HANDRAIL AS (LH) | 1 | |
| 2324641 | 4 HANDRAIL AS (RH) | 1 | |
| 2431842 | 5 HARNESS AS-SCREED (PAVER TO SCREED) | 1 | |
| 1753365 | PLUG AS-CONNECTOR | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X5615 | SEAL (INTERFACE, 70-PIN) | 2 | |
| 4B4274 | 6 WASHER (5.5X13X1.2-MM THK) | 8 | |
| 5P7162 | 7 SCREW-MACHINE (10-32X0.5-IN) | 8 | |
| 5S7382 | 8 BOLT (3/8-16X1.375-IN) | 4 | |
| 7K1181 | 9 STRAP-CABLE | 11 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T7008 | 11 BOLT (3/8-16X3-IN) | 4 | |
| 9S8752 | 12 NUT-FULL (3/8-16-THD) | 8 | |
| 6V1614 | 13 TUBE-HEAT SHRINK (9.52-MM DIA) |
