System And Components
453-2440 LINER GP-CABS/N SL91-UP
Group No: 453-2440
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4661621 | 1 HOOK-COAT | 2 | |
| 7K1181 | 2 STRAP-CABLE | 4 | |
| 4222152 | 3 LOUVER AS-VENT | 8 | |
| 1176838 | 4 STUD | 1 | |
| 1648473 | 5 LOUVER AS-VENT | 2 | |
| 1714046 | 6 LOUVER AS-VENT | 2 | |
| 1714047 | 7 LOUVER AS-VENT | 2 | |
| 2090746 | 8 STRAP | 1 | |
| 2346498 | 9 RIVET | 6 | |
| 2402169 | 10 RETAINER | 2 | |
| 3390965 | 11 STRAP | 2 | |
| 3402582 | 12 LINER (CUP HOLDER) | 2 | |
| 3419811 | 13 LINER (TRAY) | 1 | |
| 3420064 | 14 NET AS | 1 | |
| 3719555 | 15 COVER AS (LOWER, REAR) | 1 | |
| 3719559 | 16 COVER AS (REAR, LOWER) | 1 | |
| 3719570 | 17 COVER (LOWER, LH) | 1 | |
| 3719591 | 18 LINER AS-CAB | 1 | |
| 3793471 | 19 COVER | 1 | |
| 3826957 | 20 FLOOR MAT-REAR | 1 | |
| 3829323 | 21 HEADLINER | 1 | |
| 5331589 | 22 DUCT | 1 | |
| 4246355 | 23 NET AS-STORAGE | 1 | |
| 4354863 | 24 TRAY | 1 | |
| 4571119 | 25 DUCT AS | 1 | |
| 4571120 | 26 DASH AS | 1 | |
| 4571121 | 27 DUCT AS | 1 | |
| 4571662 | 28 MAT (FRONT) | 1 | |
| 4571663 | 29 FLOOR MAT | 1 | |
| 4574658 | 30 HEADLINER | 1 | |
| 4591202 | 31 COVER-POST | 1 | |
| 4591203 | 32 COVER AS (REAR) | 1 | |
| 4591204 | 33 COVER AS (LOWER, RH) | 1 | |
| 4591205 | 34 PANEL | 1 | |
| 4591206 | 35 COVER-FUSE | 1 | |
| 4591208 | 36 PANEL AS | 1 | |
| 4591209 | 37 COVER AS (CONSOLE) | 1 | |
| 4591211 | 38 COVER AS (UPPER, LH) | 1 | |
| 4604676 | 39 DUCT AS | 1 | |
| 4610913 | 40 BRACKET | 1 | |
| 4806461 | 41 PLATE | 1 | |
| 4929134 | 42 BEZEL | 1 | |
| 1042091 | 43 SCREW-FLAT HEAD (6-20X0.5-IN) | 36 | |
| 1146658 | 44 WASHER (6.5X17X1-MM THK) | 48 | |
| 1219870 | 45 SCREW-MACHINE (M6X1X40-MM) | 5 | |
| 2001131 | 46 SCREW-TRUSS HEAD (M4X0.7X20-MM) | 7 | |
| 2V2015 | 47 NUT-SPEED | 1 | |
| 3445675 | 48 NUT (M10X1.5-THD) | 3 | |
| 3E8020 | 49 SCREW-TRUSS HEAD (M6X1X25-MM) | 2 | |
| 1728591 | 50 NUT-CLIP (M6X1-THD) | 40 | |
| 7X0579 | 51 WASHER-HARD (8.8X25.5X2-MM THK) | 31 | |
| 8T4121 | 52 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4137 | 53 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4186 | 54 BOLT (M10X1.5X40-MM) | 3 | |
| 8T4222 | 55 WASHER-PLATED (11X32X2.5-MM THK) | 3 | |
| 9V3940 | 56 RETAINER | 1 | |
| 9X2044 | 57 SCREW-TRUSS HEAD (M6X1X16-MM) | 14 | |
| 9X2045 | 58 SCREW-TRUSS HEAD (M6X1X20-MM) | 59 | |
| 9X2046 | 59 SCREW-TRUSS HEAD (M6X1X35-MM) | 2 | |
| 1487361 | 60 FASTENER-HOOK & LOOP (ADHESIVE BACKED)(2.5-CM) | ||
| 1487362 | 61 FASTENER-HOOK & LOOP (ADHESIVE BACKED)(2.5-CM) | ||
| 2194361 | 62 TUBING (FLEX)(50-CM) | ||
| 2194361 | 62A TUBING (FLEX)(43.5-CM) | ||
| 5P5639 | 63 SEAL (1.1-M) | ||
| 2843953 | 64 SEAL (7.8-DM EACH) | ||
| 2843953 | 64A SEAL (4.3-DM) | ||
| 2843953 | 64B SEAL (3.3-DM) |
