System And Components
305-5532 PEDAL GP-BRAKE -LHS/N SL91-UP
Group No: 305-5532
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E9664 | 1 PIN | 1 | |
| 0093101 | 2 RING-RETAINING | 2 | |
| 1056117 | 3 SWITCH AS-LIMIT (STOP LIGHT) | 1 | |
| 1152247 | 4 SPRING | 1 | |
| 1536273 | 5 SETSCREW (M6X1X16-MM) | 1 | |
| 1633926 | 6 ROLLER | 1 | |
| 2002217 | 7 COVER | 1 | |
| 2002218 | 8 BRACKET AS-ADJUSTABLE SWITCH | 1 | |
| 2002219 | 9 BOLT (M5X0.8X25-MM) | 6 | |
| 2002220 | 10 SEAL | 1 | |
| 2661466 | 11 SENSOR GP-POSITION (ROTARY) | 1 | |
| 3817075 | 13 PEDAL | 1 | |
| 1253295 | 14 SCREW-PAN HEAD (M2.5X0.45X12-MM) | 2 | |
| 2067316 | 15 PIN | 1 | |
| 3063011 | 16 HARNESS AS-BRAKE (STOP LIGHT) | 1 | |
| 8C8514 | SCREW-MACHINE (8-32X0.375-IN) | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 5P2957 | TERMINAL-BLADE (14-GA TO 16-GA) | 2 | |
| 5P5602 | TERMINAL-BLADE (18-GA TO 22-GA) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 8T2899 | 17 SCREW-MACHINE (M2.5X0.45X6-MM) | 2 |
