System And Components
305-5533 PEDAL GP-BRAKE -RHS/N SL91-UP
Group No: 305-5533
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E9664 | 1 PIN | 1 | |
| 0093101 | 2 RING-RETAINING | 3 | |
| 1253295 | 3 SCREW-PAN HEAD (M2.5X0.45X12-MM) | 2 | |
| 1280606 | 4 COVER | 1 | |
| 1280607 | 5 SEAL | 1 | |
| 1485581 | 6 INSULATOR | 1 | |
| 1536273 | 7 SETSCREW (M6X1X16-MM) | 1 | |
| 1674348 | 8 SPRING | 1 | |
| 2007914 | 9 SHAFT AS | 1 | |
| 2053582 | 10 ROLLER | 1 | |
| 8S2225 | 11 SEAL-LIP TYPE | 1 | |
| 3817075 | 12 PEDAL | 1 | |
| 3063012 | 13 SWITCH AS-LIMIT (THROTTLE LOCK DEACTIVATION) | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 1245811 | GROMMET AS | 1 | |
| 8C8514 | SCREW-MACHINE (8-32X0.375-IN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 2 | |
| 5M6755 | 14 SCREW-MACHINE (10-24X0.562-IN) | 3 |
