System And Components
459-2178 WIPER & WASHER GP-WINDOWS/N SL91-UP
Group No: 459-2178
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4564534 | 1 PLATE | 1 | |
| 3S2093 | 2 STRAP-CABLE | 17 | |
| 3V3263 | 3 CONNECTOR (HOSE) | 2 | |
| 6V7419 | 4 BLADE AS-WIPER (700-MM)(FRONT WINDOW) | 1 | |
| 8T5400 | 5 CONNECTOR | 1 | |
| 1276509 | 6 ARM AS-WIPER (REAR) | 1 | |
| 2147635 | 7 ARM GP-WINDOW WIPER (FRONT) | 1 | |
| 2266545 | 8 BLADE AS-WIPER (300-MM)(REAR WINDOW) | 1 | |
| 3808464 | 9 TANK GP-WINDOW WASHER | 1 | |
| 3889379 | CAP-VENTED (WINDOW WASHER TANK) | 1 | |
| 4160021 | PUMP AS-WASHER (24-VOLT) | 2 | |
| 3815456 | 10 MOTOR GP-WINDOW WIPER (REAR) | 1 | |
| 4588336 | 11 MOTOR GP-WINDOW WIPER (FRONT) | 1 | |
| 4596629 | 12 GASKET | 1 | |
| 4695745 | 13 VALVE-CHECK | 2 | |
| 3E8020 | 14 SCREW-TRUSS HEAD (M6X1X25-MM) | 4 | |
| 6V8225 | 15 NUT (M6X1-THD) | 4 | |
| 8T4189 | 16 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X2038 | 18 WASHER (7X19X2-MM THK) | 4 | |
| 1440195 | 19 HOSE (249-CM) | ||
| 1440195 | 19A HOSE (14-CM) | ||
| 1440195 | 19B HOSE (13-CM) | ||
| 1440195 | 19C HOSE (165-CM) | ||
| 1440195 | 19D HOSE (39-CM) | ||
| 7X7927 | 20 TAPE-IDENTIFICATION (LETTER A)(6-CM EACH) | ||
| 7X7928 | 21 TAPE-IDENTIFICATION (LETTER B)(6-CM EACH) |
