System And Components
529-6275 LINES GP-FUELS/N NGH1-UP
Group No: 529-6275
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 9N4685 | 2 SPACER (10X20X20-MM THK) | 1 | |
| 2172985 | 3 ELBOW AS | 1 | |
| 2287102 | SEAL-O-RING | 1 | |
| 4167151 | RING-RETAINER | 1 | |
| 3535133 | 4 ELBOW AS | 1 | |
| 0307949 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3535134 | 5 ELBOW AS | 1 | |
| 1184728 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3985596 | 6 PLUG AS | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 3985601 | 7 PLUG AS | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3603681 | PLUG (7/8-14-THD) | 1 | |
| 5075206 | 8 HOSE AS | 1 | |
| 5090845 | 9 CONNECTOR AS | 1 | |
| 4515682 | SEAL | 1 | |
| 4954837 | ADAPTER-STR | 1 | |
| 5135723 | 10 HOSE & TUBE AS | 1 | |
| 5154946 | 11 ELBOW AS | 1 | |
| 2287100 | SEAL-O-RING | 1 | |
| 5154945 | ELBOW | 1 | |
| 5281015 | 12 ADAPTER AS | 1 | |
| 2287100 | SEAL-O-RING | 1 | |
| 5281014 | ADAPTER | 1 | |
| 5302618 | 13 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5303319 | 14 HOSE AS | 1 | |
| 5303320 | 15 HOSE AS | 1 | |
| 5322513 | 16 TUBE AS | 1 | |
| 1327551 | 17 SPACER (11X19X6-MM THK) | 1 | |
| 1423953 | 18 STUD (M10X1.5-THD) | 1 | |
| 2P1281 | 19 ADAPTER-STRAINER | 1 | |
| 2P1282 | 20 UNION | 1 | |
| 3445675 | 21 NUT (M10X1.5-THD) | 2 | |
| 3537952 | 22 GROMMET | 1 | |
| 3537957 | 23 GROMMET | 1 | |
| 3E4352 | 24 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 7F2050 | 25 LOCKNUT (3/4-16-THD) | 1 | |
| 7F2060 | 26 LOCKNUT (7/8-14-THD) | 1 | |
| 8T0276 | 27 BOLT (M8X1.25X45-MM) | 1 | |
| 8T1887 | 28 CLIP (SLOT) | 1 | |
| 8T1888 | 29 CLIP (TAB) | 1 | |
| 8T1897 | 30 CLIP (SLOT) | 1 | |
| 8T1898 | 31 CLIP (TAB) | 1 | |
| 8T4121 | 32 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T7934 | 33 WASHER-HARD (11X21X5-MM THK) | 1 |
