System And Components
105-2871 LINES GP-TORQUE CONV COOLERS/N 1GN1-UP
Group No: 105-2871
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P3704 | 1 SEAL-RECTANGULAR | 3 | |
| 1052089 | 2 TUBE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 8T4896 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T2502 | BOLT (3/8-16X1.125-IN) | 4 | |
| 8C6877 | 4 BOLT (7/16-14X1.75-IN) | 4 | |
| 8T5360 | 5 WASHER (12X22.5X2.5-MM THK) | 12 | |
| 2V9490 | 6 FLANGE | 1 | |
| 8B4967 | 7 SEAL-O-RING | 2 | |
| 2V9489 | 8 FLANGE | 1 | |
| 9U8809 | 9 ELBOW-OIL COOLER | 1 | |
| 3H1461 | SEAL-O-RING | 1 | |
| 6K2171 | 10 FLANGE | 1 | |
| 7X0313 | 11 BOLT (7/16-14X2.75-IN) | 7 | |
| 1052088 | 12 TUBE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 7X0312 | 13 BOLT (7/16-14X2.5-IN) | 1 | |
| 3B6552 | 14 ELBOW-PIPE | 1 | |
| 6V0852 | 15 CAP-DUST | 2 | |
| 8B1931 | 16 BUSHING-REDUCER | 1 | |
| 8T3613 | 17 FITTING | 1 | |
| 1504050 | 18 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 8T0788 | ELBOW | 1 | |
| 8T6663 | 19 ADAPTER-PORT | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1645567 | 20 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 |
