324-7748 GEAR GP-OUTPUT TRANSFERS/N J2P1-UP; J4P1-UP

Group No: 324-7748

Part Number	Part Name	Qty
2S4750	1 GASKET	1
3T6965	2 PLATE-EYE	1
4S8598	3 SCREEN-SUCTION	1
5P2526	4 CUP-BEARING	2
6V1720	5 PLATE-SERIAL NUMBER (TRANSMISSION)	1
8E9740	6 GEAR-OUTPUT TRANSFER (64-TEETH)	1
8E9741	7 GEAR-OUTPUT TRANSFER (58-TEETH)	1
8P2155	8 SPACER (61X76X43-MM THK)	1
8P3251	9 COVER AS	1
7B3028	SCREW-DRIVE (NO 4X 3/16-IN)	2
7S2962	WASHER-SPRING (52.3X82.5X9.1-MM THK)	1
8P1722	COVER	1
1168231	10 CAGE-BEARING	1
5606407	11 YOKE AS	2
1381509	12 DRAIN GP-ECOLOGY (POWER TRAIN OIL)	1
1932200	13 SEAL-LIP TYPE	2
2229874	14 RETAINER-BEARING	1
2229875	15 CAGE-BEARING	1
2263492	16 BRACKET AS	2
3685063	17 TUBE AS	1
8M7160	MAGNET	3
2653930	18 RETAINER	2
2666644	19 SHAFT-OUTPUT	1
2905792	20 SENSOR GP-SPEED	2
3223111	21 SHIM PACK (INCLUDES 12-SHIMS)	1
3306857	23 BRACKET AS	1
3343708	24 COVER	1
3468421	25 BRACKET	1
3508801	26 BRACKET	1
3510848	27 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
3524212	28 CAGE-BEARING	1
1S6595	29 GASKET-OIL SUPPLY	1
5K5959	30 SEAL-O-RING	2
1757905	31 SEAL-O-RING	1
2K5065	32 CONE-BEARING	2
2P8986	33 CUP-BEARING	2
2P8987	34 CONE-BEARING	2
3F5792	35 SEAL-O-RING	1
3K0360	36 SEAL-O-RING	2
4D1577	37 SEAL-O-RING	1
5H6734	38 SEAL-O-RING	2
5M2894	39 WASHER-HARD (10.2X18.5X2.5-MM THK)	6
5M3154	40 COVER	1
5P5411	41 RACE-BEARING OUTER	1
5P8245	42 WASHER-HARD (13.5X25.5X3-MM THK)	15
6A5591	43 BOLT (M12X1.75X25-MM)	3
6V1819	44 BOLT (M10X1.5X100-MM)	6
6V1820	45 BOLT (M10X1.5X30-MM)	3
6V3822	46 BOLT (M10X1.5X35-MM)	4
6V4248	47 BOLT (M10X1.5X25-MM)	8
6V5839	48 WASHER (11X21X2.5-MM THK)	19
6V5842	49 BOLT (M10X1.5X40-MM)	4
6V6317	50 BOLT (M10X1.5X20-MM)	2
6V8197	51 BOLT (M12X1.75X40-MM)	4
6V8675	52 BOLT (M12X1.75X35-MM)	8
7B3642	53 BEARING-INNER	1
8H7521	54 SEAL-O-RING	1
8M3107	55 COVER	1
8T0358	56 BOLT (M16X2X90-MM)	2
