System And Components
214-4796 CONTROL GP-ELECTROHYDRAULIC -JOYSTICK, SINGLE FUNCTIONS/N AYH1-563
Group No: 214-4796
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E0109 | 1 PLUG (ROCKER SWITCH) | 1 | |
| 3E3365 | 2 WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 1701821 | 3 SWITCH AS-PUSH BUTTON (HORN) | 1 | |
| 6F0253 | LOCKWASHER | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1723511 | NUT (5/8-24-THD) | 1 | |
| 2199533 | 4 SWITCH AS-ROCKER (24-VOLT)(IMPLEMENT LOCKOUT) | 1 | |
| 1861574 | 5 CONTROL GP-JOYSTICK (SINGLE FUNCTION) | 1 | |
| 1883983 | 6 SWITCH AS-PUSH BUTTON (THROTTLE LOCK RESUME) | 1 | |
| 3K0835 | NUT (5/8-24-THD) | 1 | |
| 6F0253 | LOCKWASHER | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552276 | WEDGE-PLUG LOCK (3-PIN) | 1 | |
| 1863736 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1883984 | 7 SWITCH AS-PUSH BUTTON (THROTTLE LOCK SET) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 3K0835 | NUT (5/8-24-THD) | 1 | |
| 6F0253 | LOCKWASHER | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 2071792 | 8 COVER AS | 1 | |
| 2144780 | 9 CUSHION AS | 1 | |
| 2144782 | 10 COVER | 1 | |
| 2156369 | 11 FILM (CONTROLS) | 1 | |
| 1028802 | 12 KIT-RECEPTACLE (2-PIN) | 1 | |
| 5C2890 | 13 NUT (M6X1-THD) | 4 | |
| 8T4205 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T4970 | 15 BOLT (M6X1X14-MM) | 4 | |
| 9X2044 | 16 SCREW-TRUSS HEAD (M6X1X16-MM) | 8 |
