System And Components
230-9789 TANK GP-HYDRAULICS/N ZLK1-UP
Group No: 230-9789
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1R0722 | 1 FILTER ELEMENT AS-OIL (STANDARD EFFICIENCY)(HYDRAULIC) | 4 | |
| 1U2827 | 2 GUIDE-VALVE | 1 | |
| 3D6678 | 3 STRAINER (METAL)(HYDRAULIC TANK) | 1 | |
| 3G2665 | 4 COVER | 2 | |
| 3G2689 | 5 TUBE AS-BAFFLE | 1 | |
| 3G2725 | 6 BASE-FILTER | 1 | |
| 3G2754 | 7 VALVE | 1 | |
| 3G2815 | 8 STUD | 2 | |
| 3G2817 | 9 BLOCK | 1 | |
| 3G2818 | 10 BLOCK | 2 | |
| 3G2839 | 11 GASKET | 1 | |
| 3S9733 | 12 SPRING | 1 | |
| 4J3754 | 13 CAP-FILLER (HYDRAULIC TANK) | 1 | |
| 4J3816 | 14 PLATE | 1 | |
| 7B3039 | 15 SPRING | 1 | |
| 8J8782 | 16 BODY-DRAIN VALVE | 1 | |
| 8J8783 | 17 VALVE-DRAIN | 1 | |
| 8T3298 | 18 SEAL-RECTANGULAR | 1 | |
| 9J6381 | 19 SPACER (71X108X3-MM THK) | 2 | |
| 9J6382 | 20 COVER | 1 | |
| 9J7031 | 21 PLUG-DRAIN | 1 | |
| 9J9842 | 22 BOLT-FILTER | 2 | |
| 9T7842 | 23 FILLER | 1 | |
| 1238159 | 24 BAFFLE AS | 1 | |
| 1326277 | 25 GAUGE AS-LIQUID LEVEL | 1 | |
| 8F3469 | SEAL-O-RING | 2 | |
| 1217958 | BOLT-MOUNTING (1/2-20X1.75-IN) | 2 | |
| 2309784 | 26 TANK AS-HYDRAULIC | 1 | |
| 2309787 | 27 COVER AS | 1 | |
| 7J5225 | FITTING (1-1/16-12-THD) | 1 | |
| 1070723 | BOSS (11.5-MM ID) | 2 | |
| 2381825 | 28 GASKET | 1 | |
| 0L1351 | 29 BOLT (3/8-16X0.875-IN) | 69 | |
| 1488395 | 30 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 1488410 | 31 PLUG AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 1H9696 | 32 SEAL-O-RING | 4 | |
| 2H3928 | 33 SEAL-O-RING | 1 | |
| 2J2864 | 34 PLUG-DRAIN | 1 | |
| 2J3118 | 35 BOLT-LOCKING (3/8-16X1.25-IN) | 10 | |
| 2K4973 | 36 LOCKNUT (3/8-16-THD) | 76 | |
| 2M4453 | 37 SEAL-O-RING | 2 | |
| 4J3815 | 38 GASKET | 1 | |
| 4L6454 | 39 BOLT (3/8-16X1-IN) | 6 | |
| 5H6005 | 40 SEAL-O-RING | 14 | |
| 5M2057 | 41 SEAL-O-RING | 1 | |
| 5P8248 | 42 WASHER-HARD (20X36.5X3.5-MM THK) | 2 | |
| 5S7382 | 43 BOLT (3/8-16X1.375-IN) | 2 | |
| 6D9157 | 44 SEAL-O-RING | 2 | |
| 6F0711 | 45 SEAL-O-RING | 1 | |
| 6F4855 | 46 SEAL-O-RING | 16 | |
| 6F5559 | 47 SEAL-O-RING | 1 | |
| 8F8733 | 48 SEAL-O-RING | 1 | |
| 8F8882 | 49 SEAL-O-RING | 1 | |
| 8T2275 | 50 BALL | 1 | |
| 8T4896 | 51 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 9F6656 | 52 RING-RETAINING | 2 | |
| 9H7759 | 53 RING-RETAINING | 2 | |
| 9J6379 | 54 SPRING-DISC | 12 | |
| 8T4907 | 55 SEALANT (1-M) | ||
| 9B7237 | 56 BOLT (3/8-16X1.25-IN) | 1 | |
| 0951563 | 57 SEAL-O-RING | 2 | |
| 5M2894 | 58 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 7X7729 | 59 WASHER (11X25X3-MM THK) | 6 |
