System And Components
147-2029 ADAPTER GP-FAST FILL FUELS/N 9XR1-UP
Group No: 147-2029
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G9000 | 1 VALVE AS-TANK (FAST FILL FUEL) | 1 | |
| 6G7803 | 2 VENT AS | 1 | |
| 6V9273 | 3 BALL | 1 | |
| 6Y0091 | 4 BLOCK AS | 1 | |
| 7T2413 | 5 SHAFT | 1 | |
| 8E3234 | 6 HOSE AS | 1 | |
| 9D0630 | 7 CAP-DUST | 1 | |
| 1018909 | 8 CAP AS-FILLER | 1 | |
| 9X8600 | SEAL-O-RING | 1 | |
| 1B5170 | 9 PLUG-PIPE | 1 | |
| 1P4582 | 10 FLANGE-HALF | 4 | |
| 4J0527 | 11 SEAL-O-RING | 2 | |
| 4L6454 | 12 BOLT (3/8-16X1-IN) | 1 | |
| 6V2686 | 13 CLIP | 1 | |
| 6V8801 | 14 NUT (3/8-16-THD) | 1 | |
| 7X0339 | 15 BOLT (1/2-13X6.25-IN) | 2 | |
| 8T4223 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T4896 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8T8919 | 18 BOLT (1/2-13X1.75-IN) | 8 | |
| 5T8645 | KIT-VENT (FUEL TANK) | 1 |
