System And Components
187-5279 ADAPTER GP-FAST FILL FUELS/N ABK1-UP
Group No: 187-5279
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1Q3160 | 1 HOSE AS | 1 | |
| 1Q3162 | 2 BRACKET AS | 1 | |
| 8T5911 | NUT-WELD (1/2-13-THD) | 2 | |
| 1242463 | 3 ADAPTER-FAST FILL FUEL | 1 | |
| 6Y0091 | 4 BLOCK AS | 1 | |
| 9D0630 | 5 CAP-DUST | 1 | |
| 1635455 | 6 VALVE AS-SHUTOFF (FAST FILL FUEL)(FAST FILL FUEL) | 1 | |
| 1635456 | 7 HOSE AS | 1 | |
| 1885095 | 8 VENT AS | 1 | |
| 1H8128 | 9 SEAL-O-RING | 1 | |
| 1J9671 | 10 SEAL-O-RING | 2 | |
| 1P4582 | 11 FLANGE-HALF | 4 | |
| 2D4534 | 12 BOLT-SOCKET HEAD (3/8-16X1-IN) | 6 | |
| 4J0527 | 13 SEAL-O-RING | 2 | |
| 4L6454 | 14 BOLT (3/8-16X1-IN) | 7 | |
| 5H6734 | 15 SEAL-O-RING | 1 | |
| 5P2618 | 16 CONNECTOR | 2 | |
| 6V2686 | 17 CLIP | 1 | |
| 6V8801 | 18 NUT (3/8-16-THD) | 1 | |
| 7X0340 | 19 BOLT (1/2-13X6.5-IN) | 2 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T4896 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 5P2566 | 22 BOLT (1/2-13X1.5-IN) | 4 | |
| 8T8919 | 23 BOLT (1/2-13X1.75-IN) | 4 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 |
